Anti Rust Construction Formwork Accessories Precast Lifting Four Strut Coil Inserts - China

precast lifting four strut coil inserts for building construction formwork accessories Product Information # B2 coil tie four strut can be used as a combination tie and form spreader when it is not necessary to keep the ends of the tie back from the face of the concrete # to determine the required coil tie length, subtract two times the desired or specified setback from the wall thickness # The Coil Tie is used with coil rod or plastic cones.

# We can also produce this item according to customer's requirments or drawings.

# # Type Bolt Dia.

SWL Tension(lbs) # standard-4 strut 1/2" 9, 000 # standard-4 strut 3/4" 18, 000 # standard-4 strut 1" 18, 000 # heavy-4 strut 1" 27, 000 # standard-4 strut 1-1/4" 27, 000 # standard-4 strut 1-1/2" 27, 000 Features # The CX-63 Special inserts can be manufactured to meet your unusual forming requirements, and are often used as alternatives for cantilever formwork.

The CX-63 are made using coil rod bent into a specified configuration.

These products are made to order.

- - - - type | bolt diameter | number of strut wires | saft working load tension lbs | B2 standard | 1/2 | 4 | 9000 | B2 heavy | 1/2" | 4 | 13500 | standard | 3/4 | 4 | 13500 | Heavy | 3/4 | 4 | 18000 | standard | 1 | 4 | 18000 | heavy | 1 | 4 | 27000 | standard | 1 1/4 | 4 | 27000 | heavy | 1 1/4 | 4 | 37000 | standard | 1 /12 | 4 | 27000 | - - - - Here are the pictures of formwork coil tie two strut coil ties for concrete forming tie Other concrete accessories, forming hardware, formwork accessories coil insert, loop insert, ferrule insert, coil loop insert wingnut insert coil bolt, coil cone are vailable How to use the two strut coil tie : the coil ties will fix with two coil cone plastic cone made by pvc material, the coil cone size is 1/2*35mm the coil bolt and plate washer will also fix to them on the formwork plywood panel in concrete see the assembly pictures: ORDERING INFORMATION B2, 3/4" DIA.

(13, 500 LBS.

) STANDARD 4-STRUT Product Code Description Weight 124903 .

306" X 12" PLAIN 1.35 LB B2, 3/4" DIA.

(18, 000 LBS.

) HEAVY 4-STRUT Product Code Description Weight 124156 .

375" X 6" PLAIN 1.328 LB 127310 .

375" X 6" ELECTRO GALV.

1.35 LB 124617 .

375" X 8" PLAIN 1.5 LB B2, 1" DIA.

(18, 000 LBS.

) STANDARD 4-STRUT Product Code Description Weight 41590 .

375" X 6" PLAIN 1.635 LB 124958 .

375" X 8" PLAIN 1.68 LB 40621 .

375" X 10" PLAIN 1.98 LB 40622 .

375" X 12" PLAIN 2.5 LB 128068 .

375" X 6" ELECTRO GALV.

1.66 LB 40650 .

375" X 8" ELECTRO GALV.

1.68 LB 128069 .

375" X 12" ELECTRO GALV.

2.55 LB
