Straightening Machine Straightener - China

Seven Roll Bar Straightening Machine (7 Roll Bar Straightener) This is RG Finishing, a leading provider of straightening machines, peeling machines and other finishing machines of various models in China.

Committed to produce finishing machines with best price/performance ratio, RG enjoys excellent reputation among clients across China.

To contact us, send email Machine Description:

Mainly comprised of a straightening machine, loading and unloading tables, electric control, and hydraulic, pneumatic and lubrication devices, RG vertical straightening machines with multiple (mainly seven) rolls can effectively eliminate bending at two ends, slight out-of-roundness, and oxide scales.

Advantages:

1 - Adopt optimized quasi-double curve and deep/shallow concave (evolved from convex and concave roll) shape complex rolling system, absorb the advantages of straightener with two-roll and traditional multiple skew rolls, and overcome both shortcomings, so the straightening precision is higher.

2 - Adopt the principle of double rolls pressing with controllable load, turn rigid frame into flexible one, and ensure necessary pressure on bar, thus expand the scope of bar plastic area, which can improve the straightening precision and protect mechanical equipments from damages.

3 - Main transmission adopts SIMENS's full-digital DC (or AC) gear, step-less speed, constant torque output under basic speed and constant power output above basic speed.

Besides, it adopts self-adaptive (AGC) control system, for two motors, the speed is balanced under no-load status, and the torque is balanced under load status, thus motor performance can be fully reflected.

4 - The program control adopts the PLC system, and uses PROFIBUS-DP field bus for communications, which forms an integrated automatic network together with remote I/O on operating platform and human-computer interface.

According to HMI, it is suitable for process requirements.

From front-desk feeding, adjustment of the parameters of straightening machine (including automatic regulation of straightening rolls and angles), to back-desk unloading, it can achieve full-course automatic, manual and semi-automatic controls, and it is equipped with sound/light alarming system for fault detectors.

All operations are performed on the operating platform.

5 - The hydraulic system, equipped with hydraulic station, adopts constant-pressure pump as power source and accumulator's quick supplement of oil.

The overload unloading adopts direct-acting overflow valve, which may maintain the pressure and buffer, and also provide assurance to protect mechanical equipments and enhance finished product rate.

6 - The feeder system has a variety of options for users, so as to better meet the use requirements.

Company Contact:

• Posted By: Xi'an RG Metallurgical Machinery Technology CO.,LTD

• Phone: 029-89296738

• Address: Fengcheng 9th road, Xi'an , Shaanxi , China

• Email:

• Website: http://www.rg-finishing.com/

• Business Description: Xian RG Metallurgical Finishing Equipment Co., Ltd (RG-Finishing) develops from Xian RG Metallurgical Machinery Technology Co., Ltd (RGMMT), a famous straightening machine provider in China.

  RG-Finishing is a leading company in the design, development, manufacturing, production line supply and consultancy of finishing lines for bars and tubes.

  Among other equipment, its straightening machines, peeling machines and bright steel production lines are highly recognized by the market for their best price/performance ratio.
