Gear Co2 Welding Machine Automotive Gears Transmissions Laser Soldering Equipment - China

Gear Co2 Welding Machine / Automotive Gears, Transmissions Laser Soldering Equipment Advantages of Laser welding

1 - Fast speed, heat distortion of the workpiece is small;

2 - High energy melt contact surface, welding strength is higher than the substrate;

3 - Easy automation production;

4 - More Comprehensive economic benefits.

5 - Green processing, pollution-free and pollution-free

Specification - - - -

Power | Power rating | 3000W | Power dynamic range | 300-3000W(Adjustable) | Power stabilit | <2% | Light beam | Beam mode | Fundamental mode (00 mode) | Divergence angle | <0.15 mrad (Full-shaped) | Beam diameter | 20mm-25mm( <10m) | Directivity stability <0.2 mrad | Polarized light | 45 or vertical polarization | Pulse | Super intensity pulse | 8-5000Hz | Pulse width | 26sContinuous Wave | oblique wave generator | 8-5000Hz | Gas | Laser gas | He, N2, CO2 | Laser gas consumption | Total0.2L/per hour | Electric quantity | Max Power consumption | 45KVA(380V, 50Hz) | Cooling liquid | Heat load | 39KW(environmental temp 40C) | Coolant temperature | 20C | Coolant temperature stability | Max1C | Coolant flow | Min 42L/per minute | Inlet pressure | Min 5.7bar, Max 10bar | In and out water pressure | 5bar(When the Min flow) | Environment | Temp | Environmental temp 0-40C | Relative humidity | <85% | - - - - Technical parameter of fiber laser welding - - - -

welding depth(mm) | 0.5 | 0.8 | 1 | 1 | 1 | 2 | 2 | 2 | 3 | 3 | 3 | 4 | 4 | 5 | welding power(k w) | 0.5 | 0.5 | 1 | 1.5 | 2 | 2 | 2.5 | 3 | 2 | 2.5 | 3 | 2.5 | 3 | 3 | welding speed(m/min) | 0.8 | 0.5 | 1.3 | 2.5 | 4.5 | 2 | 3 | 3.2 | 1.6 | 2 | 2.4 | 2 | 2.4 | 1 | Note: After welding of stainless steel material, welding seam the mechanics indexes are reaching or higher than the parent material properties, and the weld forming looks good, no macroscopic defects porosity, cracks appear | - - - - Welding head

Equipment uses the US LASERMECH's fiber welding head.

It is specifically for fiber-coupled laser transmission welding head intelligent design, the product is designed with a built-in smart sensors and built-in water manifold full compact design, rugged crashworthiness, stable performance, fully meet the 24 hours in- a -row working plant environment.

Operation of

the optical fiber welding head is very simple and easy to use, protecting lens and focusing lens drawer mirror chamber design can be more flexible and easy to replace, but also can better protect

the inside optical unit, in order to protect welded joints have a longer service life.

Optical fiber welding head configuration is very flexible, it can be based on the specific requirements of end-users, the optional in-line type or level of the incident, and whether to use CCD coaxial monitoring, auto-focus, side to send the wire, an air knife, coaxial nozzles, welding monitoring unit and a special focus unit module (bifocal or rectangular beam), etc.

the cooling system

Hans external cooling water recycling system with filter system for filtration.

That can decrease water change frequency into 1/6 compare with others.

Constant-temperature control ensures circuit water from frozen in Winter.

Dual temperature independent control, equipped with two sets cooling water to meet constant temperature request of laser cavity and outlet of laser.

Laser welding gear samples Our service: After-Sale Service

1 - Our after-sale network is all over the world which will provide the comprehensive after-sale service to our customer.

2 - Our commitment is as follow:

3 - One year guarantee for the whole equipment.

4 - We will answer your questions within 24hours.

5 - When Equipment warranty expires, lifelong maintenance services will be provided.

6 - After the expiry of the warranty we will offer a wide range of software support with free upgrade for lifelong
