Electrical Chamber Corrosion Salt Spray Test Equipment Plexiglass Cover - China

Electrical Chamber Corrosion Salt Spray Testing Equipment Product Application Lenpure Salt Spray Test Chamber provides the best possible laboratory simulation of natural oceanic corrosion.

Corrosion tests performed in our chamber including: Neutral Salt Spray Test(NSS); Acetic Acid Salt Spray Test(ASS); Copper Accelerated Acetic Acid Salt Spray Test (CASS); Research indicates that test results are similar to outdoors in resulting structure, morphology, and relative corrosion rates.

Specially custom-designed chambers are available Applied to standards as below: ASTM B117/IEC60068-2-11/ISO922 7/ MIL-STD-202/ASTM G85 A1/ASTM B368/ JISZ2371/ Fiat 50180/ DIN50021 etc.

- - - - Model | SM-Y-60D | SM-Y-90D | SM-Y-120D | SM-Y-160D | SM-Y-200D | Inner size | W | 600 | 900 | 1200 | 1600 | 2000 | D | 450 | 600 | 850 | 1000 | 1200 | H | 400 | 500 | 500 | 550 | 600 | Outer size | W | 1130 | 1460 | 2200 | 2600 | 3000 | D | 630 | 910 | 1200 | 1450 | 1650 | H | 1070 | 1280 | 1450 | 1550 | 1600 | Testing room volume(L) | 108 | 270 | 480 | 800 | 1440 | Brine tank capacity(L) | 15 | 25 | 40 | Max current(A) | 5 | 12 | 15 | 18 | 22 | Max Consumption Power(KW) | 1.5 | 2.5 | 3.5 | 5 | 7 | Power supply | AC220V, 50HZ | AC380V, 50HZ | Operating ambient temperature, humidity | <35, <85%RH | Testing room temperature | Brine test method(NSS ACSS)351/Erosion-resistan t testing method (CASS)501 | Pressure Pot Temperature | Brine test method(NSS ACSS)471/Erosion-resistan t testing method(CASS)631 | Brine solubility | 5% Sodium Chloride Solution or add 0.26 grams copper dichloride in the 5% Sodium Chloride Solution per liter (CuCl2 2H2O) | PH | 6.5~7.2 3.0~3.2 | Compressed air pressure | 1.000.01kgf/cm2 | Spray quantity | 1.0~2.0ml/80cm2/h (Collect 16 hours at least, take their average) | Inside and outside material | Imported corrosion resistant, anti-aging, high strength PVC board | Heater | Corrosion resistance U type titanium tube | Temperature controller | LED digital display temperature controller, touch screen controller | Spraying mode | Continuous, intermittent spraying | Defrosting device | No | Yes | Safety device | Over temperature protection switch, leakage protection, status warning lamp | - - - -
