Oilfield Drill Pipe - China

oilfield drill pipe

Drill pipe plays a decisive role in the process of drilling, it transfered the drilling torque to drill bit, in order to drilling under the well.

When it is drilling, drill pipe has complicated load, at the same time it is subjected to stress such as pulling, pressing, torsion and bending, and drill pipe string itself is an elastic system, drilling fluid in the process of drilling and the vibration of the drilling string makes the drill pipe under a great load.

Drill Pipe Type:

E75, X95, G105, S135.

steel drill pipe supplier: Found Petroleum Equipment

Technical Parameters:

Specification Nominal weight Flat end weight Outer diameter O.D. Wall thickness Steel grade Upset end for weld-on drill pipe joint lb/ft kg/m in mm in (Ton)mm 2 3/8 6.65 6.27 9.33 2.375 60.3 0.28 7.11 E, X, G, S EU

2 7/8 10.4 9.72 14.47 2.875 73 0.362 9.19 E, X, G, S IU/EU

3 1/2 9.5 8.81 13.12 3.5 88.9 0.254 6.45 E IU/EU

3 1/2 13.3 12.32 18.34 3.5 88.9 0.368 9.35 E, X, G, S IU/EU

3 1/2 15.5 14.64 21.79 3.5 88.9 0.449 11.4 E IU/EU

3 1/2 15.5 14.64 21.79 3.5 88.9 0.449 11.4 X, G, S IU/EU

4 14 12.95 19.27 4 101.6 0.33 8.38 E, X, G, S IU/EU

4 1/2 13.75 12.25 18.23 4.5 114.3 0.271 6.88 E IU/EU

4 1/2 16.6 15 22.32 4.5 114.3 0.337 8.56 E, X, G, S EU/IEU

4 1/2 20 18.71 27.84 4.5 114.3 0.43 10.92 E, X, G, S EU/IEU

5 16.25 14.88 22.16 5 127 0.296 7.52 X, G, S IU

5 19.5 17.95 26.7 5 127 0.362 9.19 E IEU

5 19.5 17.95 26.7 5 127 0.362 9.19 X, G, S EU/IEU

5 25.6 24.05 35.8 5 127 0.5 12.7 E IEU

5 25.6 24.05 35.8 5 127 0.5 12.7 X, G, S EU/IEU

5 1/2 21.9 19.83 29.52 5.5 139.7 0.361 9.17 E, X, G, S IEU

5 1/2 24.7 22.56 33.57 5.5 139.7 0.415 10.54 E, X, G, S IEU

6 5/8 25.2 22.21 33.04 6.625 168.3 0.33 8.38 E, X, G, S IEU

6 5/8 27.72 24.24 36.06 6.625 168.3 0.362 9.19 E, X, G, S IEU Mechanical Property of Friction Welding Zone Yield Strength Tensile Strength Elongation Guided Bend Impact Energy(Akv) HRC Item MPa MPa % J Standard Steel Grade Tensile Test Piece：￠12.5； Impact specimen：10×10 Charpy -V, 20℃

SY/T5561-92 Welding area Regulations E-75 ≥517 ≥689 ≥13 / Average≥20

Mini.

value≥15 / X-95 ≥609 ≥712 / / G-105 ≥655 ≥724 / / S-135 ≥724 ≥793 / /

API Welding area Regulations E-75 ≥609 ≥712 Bending plane cracks in any direction≤3.175mm Average≥27

Mini.

value≥23 HAZ内HRC≤37 X-95 ≥655 ≥724 G-105 ≥724 ≥793 S-135 ≥392

778

793 ≥421

1000 API Pipe Body Regulations E-75 ≥517

≤724 ≥689 / Average≥54

Mini.

value≥47 / X-95 ≥655

≤862 ≥724 G-105 ≥724

≤931 ≥793 S-135 ≥931

≤1138 ≥1000

Welding Drill Pipe Parameters list (According to API standard)
