Large Scale Palm Oil Mill Plant - China

Palm oil mill plant adopts the most advanced technology to extract palm oil from palm fruit.

Palm oil mill plant process( From palm fruit bunches harvest to crude palm oil):

1 - Weighing: the palm fruit should go through the weighbridge for weighing before being transported into the factory for easy cost settlement and calculation after processing.

2 - Unloading: after unloading, FFB would be sieved to remove impurities and into the conveying machinery to the sterilizer.

The time from picking to sterilizing process should not be too long.

3 - Sterilizing: after entering the sterilizer, FFB would be cooked under high pressure and temperature and prepare for the later process.

The sterilizer is the patent of our company, the quality of which is widely praised by customers at home and abroad.

4 - Threshing: FFB soften in the sterilizing process, palm fruit and empty fruit bunch would be separated by the threshing machine and sieve.

The empty fruit bunch would be sent to the orchard after hoarding as fertilizer or fuel, it can also be used for other purposes.

5 - Digesting: palm fruit after threshing would be crushed through the mixing and extrusion of the crusher.

6 - Pressing: the crushed fruit is extracted by screw palm oil press machine.

7 - Crude palm oil clarification: crude oil after pressing contains certain amount of moisture and impurities.

After the preliminary cleaning by the grit tank and vibrating screen, crude oil enters the vertical oil tank for heating and stirring then separated into waste oil and edible vegetable oil.

Edible vegetable oil after drying conveying would be sent to crude oil storage tanks.

Waste oil is recovered by the sand removing system and centrifugal separation.

As a professional palm oil processing machine manufacturer, we can try our best to satisfy your needs, at the same time, provide you factory price and give you the best after-sales service.

All in all, we will help you produce palm oil and make high profits, welcome to contact Henan Glory!
