Palm Oil Production Machine In Nigeria - China

Henan Doing Mechanical Equipment Co is a professional palm oil production machine manufacturer.

We could offer customer whole line palm oil production machines with capacity 500kg/h-5t/h-10t/h-20t/h- 30t/h-60t/h, etc.

Palm oil production machine line is very different from other common oil seeds.

It mainly includes 9 sections:

1 - Raw materials storage section of palm oil production: Fresh palm fruit bunch must be first measurement recorded by the pound into the plant, then unloaded to loaded fruit slopes and stored.

2 - Sterilizing section of palm oil production: fresh palm fruit bunch are airtight sterilized in sterilizer.

The purpose is to prevent enzymes broken down, avoiding FFA content in oil further increase; easy threshing machinery; pretreatment peel, prepared for the follow-up processing; pre-conditioning stone, reducing the damage kernel.

3 - Threshing section of palm oil production: The purpose of threshing is to separate oil palm fruit from the fruit bunch through strong vibration.

4 - Palm oil pressing section of palm oil production: Before pressed, oil palm fruit first be carried out cooking, sterilized fruit must be re-heated to make the pulp soft and damage pulp cell structure.

Then enter into continuous screw press.

5 - Palm oil clarification section of palm oil production: Machine-pressed crude oil first diluted with water washing, the fiber material removed from the oil through settlement and filtration, and then carry out continuous settlement.

6 - Finished crude palm oil is stored in storage tanks.

7 - Fiber separation section of palm oil production: Press cake broken by breaking screw conveyor and then transported into the fiber separation air net and fiber polishing roller for fiber separating.

8 - Kernel recovery section of palm oil production: After separation, shell is sent to the warehouse for temporary storage, as boiler room fuel when necessary; Dried kernel is sent to kernel storage warehouse for storing.

9 - Sewage treatment section of palm oil production: Pool sewage treatment system is the most used and effective treatment.

Company Contact:

• Posted By: Henan Doing Mechanical Equipment Co., Ltd

• Phone: +86 13526627860

• Address: No.133 Yaozhai Road, Jinshui District, Zhengzhou City, Henan Province, China , zhengzhou , Asia , China

• Email:

• Website: http://www.palmoilprocessingmachine.com

• Business Description: Henan Doing Machinery Equipment Co., Ltd. has been dedicated to the research and development of large, medium-sized and small -sized palm oil processing machine and a variety of edible oil extraction machine for years.

  We are professional manufacturing enterprise which gather development, design, production, sales, installation and after-sales service in one.

  Our palm oil processing machine and palm kernel oil processing machine have gained many achievements and awards.

  And we have installed palm oil processing machine in more than 30 countries over the world.

  Such as Malaysia, Indonesia, Thailand, Nigeria, Liberia, Kenya, Ghana, Cote d'Ivoire, Congo, Zambia and so on.
