Airplane Parts Brazing Vacuum Heat Treatment Furnace With Compact Structure - China

Small Area Vacuum Brazing Furnace With Airplane Parts For Brazing Of Parts I.

Overview Vacuum brazing furnace is principally adopted in Al brazing, Cu brazing and stainless-steel brazing of aerospace devices, electronic communicating devices, home appliances, heat exchanger and various heat radiators.

II.

Technical specifications - - - - Specification/ Model | EFZK-QH-50 | EFZK-QH-100 | EFZK-QH-200 | EFZK-QH-300 | EFZK-QH-400 | | Rated loading capacity (kg) | 50 | 100 | 200 | 300 | 400 | | | Max.

furnace temperature (C) | 1350 | | Rated power(kW) | 50 | 90 | 120 | 150 | 180 | | Rated supply voltage (V) | 380 | | Rated heating voltage (V) | Based on design.

Furnace-front transformer is equipped.

| | Ultimate vacuum degree (Pa) | 6.67 (empty furnace in cold status) | | Vacuum pressure rising rate (Pa/24h) | 50 | | Gas cooling pressure (Mpa) | 0.1Mpa | | Working zone size (mm) | 300*300*400 | 300*300*500 | 450*400*670 | 450*400*850 | 600*600*1000 | | | Configuration of vacuum system | Rotary vane pump+ Roots pump | | Note: The above is standard configuration which is adjustable based on customer requirements.

| | - - - - III.

Features 1 - Single chamber, interior heating, cool wall, vertical and horizontal layout are all available with compacted structure.

Customers avail from various choices to fit their specific application needs.

2 - Heating chamber of this vacuum brazing furnace is fitted with temperature control deployed in several zones.

Hence, outstanding heat uniformity is aggressively guaranteed.

3 - Well-conceived thermal insulation shield is available in this vacuum brazing furnace, whereby promoting heat efficiency.

4 - Vacuum system of this vacuum brazing furnace comes with specialized condensation filter to eliminate pollution that brazing flux vapor brings to vacuum pump.
