Composition Caldron Industrial Microwave Furnace Small Power High Pressure - China

Laboratory Microwave High Pressure Composition Caldron Industrial Microwave Furnace As a kind of advanced heating technology in the world currently, microwave heating makes use of microwave penetration and selective heating characteristics to heat the overall material inside the insulation layer directly and rapidly.

Its heating rate is 10-100 times faster than that of the traditional furnace.

Microwave high pressure composition caldron jecket material is pressure vessel, material of dissolve cup is teflon.

Fasten the cover with body then can be sealed, the performance of sealed is secular stability without leakage.

The maximum temperature is 210;The maximum pressure is 3Mpa.

Equipment continuous operation stability is strong.

It's suitable for various experimental materials.

Microwave high pressure composition caldron applied to petrochemical engineering, biomedicine, material science, geology chemical, environmental sciences, center of disease control and prevention, food science, commodity inspection, etc.

Features 1, Small power, microwave powe 1.5KW.

2, 7 inch touch screen to make operation simple.

3, Inside of the caldron has a stirring and rapid speed cooling coil.

4, Caldron cover is liftable and rotatable, has function of feeding and discharging on line.

5, Maintain microwave heating and electric heating in the same time, powerful.

6, The dimension of equipment is small, occupation of land0.5m 7, Can reaction under high pressure of strong acid and strong base.

8, Less microwave leakage (0.05mw/cm) which is much less than national standard(5mw/cm) 9, Fast temperature rising rate with max.

10/min.

Technical Parameters 1, Power: 22010V 50Hz 2, Rated power: 4KW 3, Microwave output power: 0.011.4 KW continuously adjustable 4, Electric heating rated power: 1.5KW 5, Microwave frequency: 2.45GHz 6, Maximum temperature: 210 7, Working temperature: 200 8, Heating volume: 1L 9, Temperature rising rate: 10/min 10, Temperature control precision: 0.5% 11, Control system: PLC control with touch screen operation; automatic, manual and thermostatical control methods; 40 programmable technology curves available; curve real-time display; data storage and export; 12, Microwave leakage: 0.05mw/cm 13, Safety alarm: overcurrent alarming, overtemperature alarming Key Configuration 1, A set of furnace body(strong acid/base resistance according to the raw material of customers) 2, Industrial-grade water cooling microwave heating system 1 sets 3, One set of PLC, one set of 7 inch touch screen 4, One set of handhold microwave leakage detection instrument, a set of compression resistance vessel 5, A set of water cooling line system, a set of feeding on line device, a set of discharging on line device 6, A set of operation tool - - - - Model | Voltage | Rated power | Microwave rated power | Max.

temperature (C) | Working temperature | Temperature rising rate: | Heating zone | Furnace dimension | V | KW | KW | | | /min | mm | W*H*L(mm) | CE-PCK200C-S | 220V | 2.5 | 1.5 | 210 | 200 | 10 | (1L) | 600*600*1200 | CE-PAK200C-S | 220V | 2.5 | 1.5 | 210 | 200 | 10 | (1L) | 600*600*1200 | CE-PSK200C-S | 220V | 2.5 | 1.5 | 210 | 200 | 10 | (1L) | 600*600*1200 | - - - -
