Continuous Industrial Microwave Furnace Decomposition Drying Carbonation - China

Biomass Continuous Microwave Pyrolysis Furnace Decomposition Drying Carbonation Biomass continuous microwave pyrolysis furnace is a kind of microwave fast heating horizontal continuous furnace, with automatic feeding, automatic discharge, gas solid phase separation, mainly for experimental and production of biomass, coal, plastics, rubber, organic waste, etc., greatly improve production efficiency and product results.

Biomass continuous microwave pyrolysis furnace consists of microwave heating system, feeding device, discharging device, poly energy heating chamber, programmable control system, microwave full shielding structure, touch screen operation, electric heating device, special insulation module and furnace tube kit.

The Touch screen operation can be 40 programmable technology curves available, with data storage, export experimental data; can be manual, automatic, thermostatical control methods, curve real-time display.

Features 1, Fast temperature rising rate with max.

100/min.

2, Automatic feeding and discharging, solid gas separation, simple and convenient operation 3, Accurate measurement of temperature, measuring the material center temperature 4, Can pump a variety of flowing atmosphere 5, 7 inch touch screen to make operation simple.

6, Insulation fiber lightweight structure, energy saving efficient, good uniformity.

7, Less microwave leakage (0.05mw/cm) which is much less than national standard(5mw/cm) Technical Parameters 1, Power: 38010V 50Hz 2, Rated power: 7.5KW 3, Microwave output power: 0.01~4.2KW continuously adjustable 4, Microwave frequency: 2.45GHz 5, Ultimate temperature: 1100 6, Continuous working temperature: 900 7, Heating zone: 100500mm 8, Handling capacity: 11.5kg/h 9, Temperature rising rate: 100/min 10, Atmosphere: Protective atmosphere or reduction atmosphere 11, Temperature control precision: 0.5% 12, Control system: PLC control with touch screen operation; automatic, manual and thermostatical control methods; 40 programmable technology curves available; curve real-time display; data storage and export; 13, Microwave leakage: 0.05mw/cm 14, Safety alarms: overheating alarm, over-temperature alarm 15, Furnace dimension: 13007802000mm Key Configuration 1, One set of 304 stainless steel water-cooling furnace body 2, Industrial-grade water-cooling microwave heating system 3 sets 3, One set of 1600 heat preservation bucket, 2 sets of Furnace tube kit 4, One set of PLC, one set of 7 inch touch screen, 3 sets of thermocouple 5, One set of feeding device, one set of discharge device, one set of the transmission device.

6, One set of sealing flange, one set of atmosphere control pipeline and flow meter 7, One set of handhold microwave leakage detection instrument 8, One set of electric heating device 9, One set of condensation unit - - - - Model | Voltage | Rated power | Microwave rated power | Max.

temperature (C) | Working temperature | Temperature rising rate | Heating zone | Furnace Dimension | V | KW | KW | | | /min | mm | W*H*L(mm) | CE-PY1100C-S | 220V | 2.5 | 1.5 | 1100 | 900 | 100 | 70*160 | 600*500*1200 | CE-PY1100C-M | 220V | 5 | 3 | 1100 | 900 | 100 | 120*200 | 850*550*1200 | CE-CP1100C-S | 380V | 7.5 | 4.5 | 1100 | 900 | 100 | 100*500 | 1300*780*2000 | CE-BP1100C-S | 380V | 7.5 | 4.5 | 1100 | 900 | 100 | 100*500 | 1300*780*2000 | - - - -
