Highlighted Companies

Conventional Bolt Pipe Welding Rollers Wireless Remote Control - China

price: check with company for price

Conventional Bolt Pipe Welding Rollers Wireless Remote Control

Products Photos Catalog Conventional Bolt Pipe Photos Catalog

Conventional Bolt Pipe Welding Rollers Wireless Remote Control Quick Detail: # The bolt adjusting rotator is suitable for circular pipe/tank/vessel welding.

# The distance between wheels can be adjustable by bolt.

# There are several specifications for customer choice; we also can special design according to customers requirements.

Description: The distance between two rollers can be adjustable by bolt fasten, to accommodate work-piece of variable diameters.

The equipment features in good adaptation, smooth revolve, VFD adjustable revolve speed and displaying in linear speed, which is suitable for welding, polishing, assembly for pipe/tank/vessel longitudinal and transverse seam welding.

Our company also can customize welding rotator in all varieties according to client's requirements.

Applications: It used in many industries such as pressure vessel, boiler, freezing equipment, power station construction, metallurgical, engineering machinery, marine building, and petro-chemical industries etc.

Specifications: - - - - Type | Max loading (kg) | Range of suitable work piece(mm) | Dia.

and width of the wheel(mm) | roller linear velocity(m/h) | Power of motor(kw) | Adjustable mode for space | Way of setting | Rubber rollers | Metal rollers | XHGK-2 | 2000 | 200-1200 | 200100 | 219016 | 6-60 | 20.18 | Manual screw adjustment or bolt shift | AC converter stepless speed adjust | XHGK-5 | 5000 | 250-2300 | 250100 | 224020 | 6-60 | 20.37 | XHGK-10 | 10000 | 300-2800 | 300120 | 229025 | 6-60 | 20.55 | XHGK-20 | 20000 | 500-3500 | 350120 | 234035 | 6-60 | 21.1 | XHGK-40 | 40000 | 600-4200 | 400120 | 239045 | 6-60 | 21.5 | XHGK-60 | 60000 | 750-4800 | 450120 | 244060 | 6-60 | 22.2 | Bolt shift | XHGK-80 | 80000 | 850-5000 | 500120 | 249070 | 6-60 | 23 | XHGK-100 | 100000 | 1000-5500 | 500120 | 2490100 | 6-60 | 24 | XHGK-150 | 150000 | 1100-6000 | / | 620220 | 6-60 | 24 | XHGK-250 | 250000 | 1100-7500 | / | 660260 | 6-60 | 25.5 | XHGK-400 | 400000 | 1100-7500 | / | 750320 | 6-60 | 27.5 | XHGK-500 | 500000 | 1100-7500 | / | 750400 | 6-60 | 211 | - - - - Note: For 2-100T roller is steel and rubber combination roller.

For 100-500T roller is made of whole steel roller or imported rubber.

Reference Photos


Company Contact:


  • Phone: 86-510-83050787

  • Address: 100# Tianshun Road, Yangshan Associated Industrial Park, Huishan Economic Development Zone, Wuxi Cit, Wuxi , Jiangsu , China

  • Email: Email


Published date: March 22, 2018

  • Business Description: WUXI GUOHENG MACHINERY CO., LTD is founded in 2003 which has a history of more than ten years in the design, development and manufacturing of offshore&onshore wind tower welding equipment, CNC cutting equipment and H beam/box beam steel structure welding line.
