Directional Solidification Vacuum Heat Treatment Furnace High Degree Automation - China

High Degree Of Automation Vacuum Directional Solidification Furnace With Cobalt - based For Car I.

Overview This series of vacuum directional solidification furnace is a modern equipment working for melting metal or alloy with medium-frequency induction heating under vacuum, forming thermal gradient with specialized-designing holding furnace and cooling system, and production of directional solidified and single-crystal parts by pulling down mechanism.

It can strictly control temperature and alloy content of materials.

This furnace is primarily applied to the production of silver-based, iron-based, and cobalt-based high-temperature alloys, and the high-quality products made of these alloys are commonly practiced into aerospace turbine engine industry, vehicle, chemistry field and entertaining fields.

II.

Technical specifications - - - - Model | EF-ZKD-25 | EF-ZKD-100 | Capacity (based on steel) (kg) | 25 | 100 | Pressure rising rate (Pa/h) | 0.67 | Ultimate vacuum | 6.6710-3Pa/1Pa | Working vacuum degree | 6.6710-2Pa/10Pa | Input power supply | 3 phase, 380V10%, 50Hz | Output frequency (Hz) | 2500 | Supply power (kW) | 60 | 160/200 | Total power (kVA) | 100 | 280 | Output voltage (V) | 375 | Max.

working temperature (C) | 1700 | Total weight (calculated value) (t) | 4 | 8 | Cooling water consumption (m3/h) | 2.7 | 4.8 | Cooling water pressure (MPa) | 0.2~0.4 | Input water temperature (C) | 20 | Holding furnace power | Two stages (three stages) | Holding furnace heating method | Resistance heating (induction heating) | Note: The above is standard configuration which is adjustable based on customer requirements.

| | | | - - - - III.

Features 1 - Overall designing furnace, occupying small area 2 - Intelligent control system 3 - Process accurate controlling technology It adopts variable-frequency speed regulating motor to precisely control the elevation of fixed model; High-effective power control (IGBT/PID); Temperature correction control (infrared/thermocouple).

4 - Security Advantages Large-scale explosion-proof device; Automatic pressure relief device; Back-pressure filling device; Leakage checking apparatus.
