Double Layer Water Cooled Structure Vacuum Hot Press Furnace For Cemented Carbide - China
price: contact company for price
Vacuum Hot Press Furnace Overview The vacuum hot press furnace is batch type furnace and heating methods include graphite heating, molybdenum heating and medium frequency heating.
The crystal grain of nanometer materials can be restrained to grow.
Technical specifications - - - - Model | Rated power | Max.
working temperature | Hot zone | Ultimate vacuum | Max.
pressure | Stroke | EF-40-20Y | 40kW | 2000C | 160 160 | 5 10-3 Pa | 20T | 100mm | - - - - Features 1 - High automation and safe operation.
The control system has the sound and light alarms and protection functions of abnormal phenomena such as water break, over-temperature, over-current and automatic switch failure of thermocouple.
2 - Suitable distribution of heating elements (graphite, molybdenum or induction heating) to improve heat uniformity.
3 - Dedicated design on furnace structure to reduce evacuation time.
4 - Double-layer water jacket cooled structure on furnace shell to improve cooling rate.
Company Contact:
- Posted By: Easy Fashion Metal Products Co., Ltd.
- Phone: 86-731-84411671
- Address: Rm.1-701, No.399 Tongzipo Rd., Changsha, RPC, 410000, Changsha , Hunan , China
- Email:
Published date: March 15, 2018
- Business Description: Our technology originates from our research on customer needs and application fields.
In the process of continuous communication and collaboration with customers, we customize the best solution for customers with our technology and experience.
