Fast Cooling Vacuum Oil Quench Furnace Simple Operation For Die Steel - China
price: contact company for price
Vacuum Oil Quenching Furnace I.
Overview It is mainly applied to quenching heat treatment of high-speed steel, die steel, titanium alloy, etc.
Various technology choices and processing application range are provided with full-automatic programmable controlling.
II.
Technical specifications - - - - Model | EF-ZKQY-100 | Effective heating zone (mm) | 1000*600*450 | Max.
temperature (C) | 1350 | Furnace temperature homogeneity(C) | 5 | Ultimate vacuum degree | 2*10-1 | 6.7*10-3 | Pressure rising rate (Pa/h) | 0.67 | Gas cooling pressure (bar) | 2 | Heating power (kW) | 100 | Heating elements | Graphite and molybdenum | Note: The above is standard configuration which is adjustable based on customer requirements.
| - - - - III.
Features 1 - Vacuum degree and air cooling pressure are allowed to be adjusted to fit specific materials.
2 - Simple operation and flexible input ensure stable performance.
Manual and automatic operation can be switched readily.
Moreover, alarms will be triggered automatically on failures of the vacuum oil quench furnace.
3 - Unique gas cooling system comes with built-in air channel for maximized cooling efficiency.
4 - This vacuum oil quenching furnace is fitted with high efficiency external oil cooling circulation system for quench.
5 - Oil tank has large capacity.
Inside the tank, there are nozzles in various directions.
As a result, there will be intense convection and turbulence during oil spraying, whereby catering to quench for large workpieces.
Company Contact:
- Posted By: Easy Fashion Metal Products Co., Ltd.
- Phone: 86-731-84411671
- Address: Rm.1-701, No.399 Tongzipo Rd., Changsha, RPC, 410000, Changsha , Hunan , China
- Email:
Published date: March 14, 2018
- Business Description: Our technology originates from our research on customer needs and application fields.
In the process of continuous communication and collaboration with customers, we customize the best solution for customers with our technology and experience.
