Gas Quenching Vacuum Heat Treatment Furnace With High Stable Performance - China

Vacuum Gas Quenching Furnace I.

Overview The vacuum gas quenching furnace is the cutting-edge vacuum heat treatment equipment featuring prominent properties and unique design.

This high pressure gas quenching furnace is the industry-proven solution to gas quenching and bright annealing of high precision alloy steel parts such as high-speed steel, die steel, stainless steel, alloy steel and titanium alloy, etc.

It is also applicable for the sintering and fast cooling of magnetic materials.

II.

Technical specifications - - - - Model | EF-VQG50 | EF-VQG100 | EF-VQG200 | EF-VQG300 | EF-VQG400 | Rated loading capacity (kg) | 50 | 100 | 200 | 300 | 400 | Max.

furnace temperature (C) | 1350 | Temperature controlling precision (C) | 5 | Rated power (kW) | 50 | 90 | 120 | 150 | 180 | Rated supply voltage (V) | 380 | Rated heating voltage (V) | Based on design.

Furnace-front transformer is equipped.

| Ultimate vacuum degree (Pa) | 6.67 (empty furnace in cold status) | Vacuum pressure rising rate (Pa/24h) | 50 | Gas quenching pressure (Mpa) | 1.0 (absolute pressure) | Working zone size (mm) | 300300400 | 300300500 | 450400670 | 450400850 | 6006001000 | Configuration of temperature controlling system | Programmable regulator of Japan SHIMADEN | Configuration of vacuum system | Rotary vane pump+Roots pump | Note: The above is standard configuration which is adjustable based on customer requirements.

| - - - - III.

Features 1 - Featuring annular radiator made from copper tube in large diameter, vacuum gas quenching furnace delivers fast cooling effect.

2 - Air nozzle is 360 deployed around heating chamber uniformly.

As a result, optimal cooling effect ensures minimized deformation on workpieces.

3 - Heating component is also 360 placed around the heating chamber, ensuring high energy efficiency, low heat loss and balanced heating effect.

4 - It adopts new type of composite hard felt/metal shield as thermal insulation plate with heating function.

Customers avail from outstanding resistance against heat, pressure and air scour, as well as prolonged service life.

5 - Flexible programming input and stable mechanical performance ensure exceptional stability and low maintenance.

Integrated safety system and failure alarms facilitate reliability.
