Industrial Vacuum Heat Treatment Furnace High Thermal Efficiency For Copper Material - China

High Thermal Efficiency Small Area Vacuum Brazing Furnace With Copper For Brazing Of Parts I.

Overview Vacuum brazing furnace is principally adopted in Al brazing, Cu brazing and stainless-steel brazing of aerospace devices, vehicle components, home appliances, heat exchanger and various heat radiators.

II.

Technical specifications - - - - Specification/ Model | EFZK-QH-50 | EFZK-QH-100 | EFZK-QH-200 | EFZK-QH-300 | EFZK-QH-400 | | Rated loading capacity (kg) | 50 | 100 | 200 | 300 | 400 | | | Max.

furnace temperature (C) | 1350 | | Temperature controlling precision (C) | 5 | | Rated power(kW) | 50 | 90 | 120 | 150 | 180 | | Rated supply voltage (V) | 380 | | Ultimate vacuum degree (Pa) | 6.67 (empty furnace in cold status) | | Gas cooling pressure (Mpa) | 0.1Mpa | | Configuration of temperature controlling system | Programmable regulator of Japan SHIMADEN | | Configuration of vacuum system | Rotary vane pump+ Roots pump | | Note: The above is standard configuration which is adjustable based on customer requirements.

| | | | | | | | | | | | - - - - III.

Features 1 - Heating chamber of this vacuum brazing furnace is fitted with temperature control deployed in several zones.

Hence, outstanding heat uniformity is aggressively guaranteed.

2 - Single chamber, interior heating, cool wall, vertical and horizontal layout are all available with compacted structure.

Customers avail from various choices to fit their specific application needs.

3 - Well-conceived thermal insulation shield is available in this vacuum brazing furnace, whereby promoting heat efficiency.

4 - Vacuum system of this vacuum brazing furnace comes with specialized condensation filter to eliminate pollution that brazing flux vapor brings to vacuum pump.
