Large Scale Rotary Industrial Microwave Furnace Touch Screen Good Sealing - China

Large-scale microwave rotary furnace Overview As a kind of advanced heating technology in the world currently, microwave heating makes use of microwave penetration and selective heating characteristics to heat the overall material inside the insulation layer directly and rapidly.

Its heating rate is 10-100 times faster than that of the traditional furnace.

Large-scale microwave rotary furnace is a kind of microwave fast heating atmosphere intermittent rotary furnace, can be vacuumize, pump the atmosphere, suitable for lithium-ion battery positive and negative materials (lithium iron phosphate, lithium manganese oxide, lithium cobalt oxide, ternary materials, graphite anode material, binary cell material, lithium nickel cobalt oxide, etc.

), rare earth materials, catalyst (titanium silicon molecular sieve, ZSM-5, etc.

), magnetic material powder, powder metallurgy powder, non-ferrous metal powder and other particulate matter reaction, reduction, synthesis and so on.

Technical specifications - - - - Model : | Voltage | Rated power | Microwave rated power | Max.

temperature (C) | Working temperature | Temperature rising rate: | Heating zone: | Furnace Dimension | V | KW | KW | | | /min | mm | W HL(mm) | CE-IR1100C-S | 220V | 3 | 1.5 | 1100 | 1000 | 100 | 70*160 | 650*700*1200 | CE-IR1100C-M | 220V | 5 | 3 | 1100 | 1000 | 100 | 120*160 | 700*750*1200 | CE-IR1100C-L | 380V | 10 | 6 | 1100 | 1000 | 100 | 180*240 | 800*850*1200 | - - - - Features, 1 - Fast temperature rising rate with max.

100/min.

2 - Good Uniformity, the material stir dynamic in the furnace flip 3 - Good sealing, can be vacuum, a variety of atmosphere experiments 4.7 inch touch screen to make operation simple 5 - Insulation fiber lightweight structure, energy saving efficient, 6 - good uniformity.

7 - Less microwave leakage (0.05mw/cm) which is much less than national standard(5mw/cm)
