Non Contact Heating Industrial Microwave Furnace For Plastic Processing - China

Non-contact Heating Large Microwave Ashing Furnace Plastic Processing Large Microwave Ashing Furnace is a kind of air atmosphere microwave fast heating high temperature furnace.

Compared with the traditional ashing furnace, it saves 97% time and increases testing efficiency greatly and environmentally by using air convection exhaust system.

As a kind of advanced heating technology in the world currently, microwave heating makes use of microwave penetration and selective heating characteristics to heat the overall material inside the insulation layer directly and rapidly.

Its heating rate is 10-100 times faster than that of the traditional furnace.

Non - contact heating, no deviation of ashing.

Its widely used in fields of Food, Pharmaceutical, Polymer, Oil, Feed, Plastics, Coal quality etc.

Features 1 - Fast temperature rising rate with max.

100C/min.

2 - High ashing efficiency with max.

handling 40 pieces of samples.

3 - Insulation fibre lightweight structure to save energy and realize high efficiency.

4 - 7 inch touch screen to make operation simple.

5 - Enhanced air exchange to speed up oxidation rate.

6 - Less microwave leakage (0.05mw/cm) which is much less than national standard(5mw/cm) Technical Parameters 1 - Power: 38010V 50Hz 2 - Rated power: 10KW 3 - Microwave output power: 0.015.6 KW continuously adjustable 4 - Microwave frequency: 2.45GHz 5 - Ultimate temperature: 1200C 6 - Continuous working temperature: 1100C 7 - Heating zone: 240220200mm 8 - Temperature rising rate: 100C/min 9 - Temperature control precision: 0.5% 10 - Control system: PLC control with touch screen operation; automatic, manual and thermostatical control methods; 40 programmable technology curves available; curve real-time display; data storage and export; 11 - Microwave leakage: 0.05mw/cm 12 - Safety alarms: overheating alarm, furnace door closing alarm, over-temperature alarm 13 - Furnace dimension: 11006001700mm Key Configuration 1 - One set of 304 stainless steel furnace body 2 - Industrial-grade microwave heating system 4 sets 3 - One set of 1600C heat preservation module, 20 sets of crucibles, 2 sets of load bearing boards 4 - One set of PLC, one set of 7 inch touch screen 5 - One set of handhold microwave leakage detection instrument, one set of microwave blocker.

6 - One set of operation gloves and one set of crucible clamp.

- - - - Model | Voltage | Rated Power | Microwave rated power | Max.

temperature (C) | Working temperature | Temperature rising rate: | Heating zone | Furnace dimension | V | KW | KW | | | /min | mm | W*H*L(mm) | CE-AS1200C-S | 220V | 2.5 | 1.5 | 1200 | 1100 | 100 | 150*120*83(2L) | 560*600*700 | CE-AS1200C-L | 380V | 10 | 6 | 1200 | 1100 | 100 | 240*220*200(10L) | 1100*600*1700 | - - - -
