Small Leakage Industrial Microwave Furnace With 7 Inch Touch Screen - China

Small Microwave Leakage Continuous Graphene Microwave Reduction Furnace Industrial Microwave Furnace As a kind of advanced heating technology in the world currently, microwave heating makes use of microwave penetration and selective heating characteristics to heat the overall material inside the insulation layer directly and rapidly.

Its heating rate is 10-100 times faster than that of the traditional furnace.

Continuous graphene microwave reduction furnace is a type of microwave rapid heating atmosphere continuous reduction puffing furnace.

Apply to reduce puffing at the moment of graphene oxide.

Produce high quality graphene, has function of continuous produce, daily output is 5000~20000g.

Continuous small-scale production.

It's very suitable for graphite production.

Features 1, Fast temperature rising rate with max.

500/min.

2, 7 inch touch screen to make operation simple.

3, Insulation fibre lightweight structure to save energy and realize high efficiency.

4, Atmosphere protection, atmosphere controllable 5, Less microwave leakage (0.05mw/cm) which is much less than national standard(5mw/cm) Technical Parameters 1, Power: 38010V 50Hz 2, Rated power: 15KW 3, Microwave output power: 0.018.4 KW continuously adjustable 4, Microwave frequency: 2.45GHz 5, Ultimate temperature: 1000 6, Continuous working temperature: 900 7, Heating zone: 230700mm 8, Output: 5000~20000g/d 9, Temperature rising rate: 500/min 10, Temperature control precision: 0.5% 11, Atmosphere: protection atmosphere, flow gas controllable 12, Control system: PLC control with touch screen operation; automatic, manual and thermostatical control methods; 40 programmable technology curves available; curve real-time display; data storage and export; 13, Microwave leakage: 0.05mw/cm 14, Safety alarm: overcurrent alarming, overtemperature alarming 15, Furnace dimension: 300012002200mm Key Configuration 1, One set of 304 stainless steel furnace body 2, Industrial-grade microwave heating system 6 sets 3, One set of 1600Insulation barrels, 2 pieces furnace tube 4, One set of PLC, one set of 7 inch touch screen 5, One set of sealed flange, one set of atmosphere pilot line and flowmeter 6, One set of feeding device, discharging device, 2 pieces of pneumatic valves, a set of sealed valve, a set of SS sealed stock bin 7, One set of handhold microwave leakage detection instrument - - - - Model | Voltage | Rated power | Microwave rated power | Max.

temperature | Working temperature | Temperature rising rate | Heating zone | Furnace dimension | V | KW | KW | | | /min | mm | W*H*L(mm) | CE-GR1000C-S | 380V | 5 | 3 | 1000 | 900 | 50 | 130*180(2.4L) | 1500*600*1300 | CE-GR1000C-M | 380V | 15 | 9 | 1000 | 900 | 30 | 230*700(30L) | 3000*1200*2200 | CE-RP1000C-M | 380V | 15 | 9 | 1000 | 900 | 30 | 230*700(30L) | 3000*1200*2200 | - - - -
