Small Space Quenching Vacuum Heat Treatment Furnace With High Speed Steel - China

Vacuum Oil Quenching Furnace I.

Overview It is mainly applied to quenching heat treatment of high-speed steel, die steel, Martensitic stainless steel, titanium alloy, etc.

Various technology choices and processing application range are provided with full-automatic programmable controlling.

II.

Technical specifications - - - - Model | EF-ZKQY-50 | Heating power (kW) | 70 | Loading capacity (kg/batch) | 100 | Effective heating zone (mm) | 550*380*250 | Furnace temperature homogeneity(C) | 5 | Pressure rising rate (Pa/h) | 0.67 | Gas cooling pressure (bar) | 2 | Max.

temperature (C) | 1350 | Heating elements | Graphite and molybdenum | Note: The above is standard configuration which is adjustable based on customer requirements.

| - - - - III.

Features 1 - With compacted double chambers structure, vacuum oil quenching furnace is integrated with optimal layout for space efficiency.

2 - Oil tank has large capacity.

Inside the tank, there are nozzles in various directions.

As a result, there will be intense convection and turbulence during oil spraying, whereby catering to quench for large workpieces.

3 - Simple operation and flexible input ensure stable performance.

Manual and automatic operation can be switched readily.

Moreover, alarms will be triggered automatically on failures of the vacuum oil quench furnace.

4 - This vacuum oil quenching furnace is fitted with high efficiency external oil cooling circulation system for quench.

5 - Furnace tank of this vacuum quench furnace is heated as a whole unit.

Internal charging trays are in stacking structure.

Feeding speed is frequency regulated in slow-fast-slow mode, thus ensuring stable feeding and reduced time.

6 - Vacuum degree and air cooling pressure are allowed to be adjusted to fit specific materials.

7 - Unique gas cooling system comes with built-in air channel for maximized cooling efficiency.
