Tube Microwave Furnace High Temperature 7 Inch Touch Screen Simple Operation - China

Microwave High Temperature Tube Furnace Overview As a kind of advanced heating technology in the world currently, microwave heating makes use of microwave penetration and selective heating characteristics to heat the overall material inside the insulation layer directly and rapidly.

Its heating rate is 10-100 times faster than that of the traditional furnace.

As a kind of microwave fast heating high temperature furnace, microwave high temperature tube furnace is particularly suitable for dynamic atmosphere and vacuum high temperature tests in science and research lab.

It is consisted of microwave heating system, heat shaped cavity, the programmable control system, microwave shielding structure, touch screen operation, atmosphere device, special thermal insulation module, the furnace tube and so one.

Its controlled by PLC control with touch screen operation: automatic, manual and thermostatical control methods; 40 programmable technology curves available; curve real-time display; data storage and export.

Technical specifications - - - - Model | Voltage | Rated power | Microwave rated powe | Max.

temperature (C) | Working temperatu r | Temperature rising rate | Heating zone | Furnace Dimension | V | KW | KW | | | /min | mm | W HL(mm) | CE-CT1200C-S | 220V | 2.5 | 1.5 | 1200 | 1100 | 100 | 70*160 | 1200*500*1100 | CE-TU1200C-S | 220V | 2.5 | 1.5 | 1200 | 1100 | 100 | 70*160 | 600*500*1200 | CE-TU1200C-M | 220V | 5 | 3 | 1200 | 1100 | 100 | 100*200 | 850*550*1200 | CE-TU1600C-S | 220V | 5 | 3 | 1600 | 1550 | 50 | 70*160 | 850*550*1200 | CE-LT1200C-S | 220V | 2.5 | 1.5 | 1200 | 1100 | 100 | 70*160 | 500*700*800 | CE-ST1200C-S | 220V | 2.5 | 1.5 | 1200 | 1100 | 100 | 70*160 | 1200*500*1100 | CE-ST1200C-M | 220V | 5 | 3 | 1200 | 1100 | 100 | 70*300 | 1400*500*1100 | - - - - Features # # Fast temperature rising rate with max.

100C/min.

# 7 inch touch screen to make operation simple.

# Insulation fibre lightweight structure to save energy and realize high efficiency.

# Vacuumize the furnace then pump into atmosphere(at least two options).

# Small furnace dimension with floor occupation 0.5m # Less microwave leakage (0.05mw/cm) which is much less than national standard(5mw/cm)
