Professional Disc Oil Separator Liquid Solid Separation Centrifuge High Rotating Speed - China

Centrifuge Solid Liquid Separation Disc Oil Separator High Rotating Speed Hot Sale Product Description Disc type liquid liquid solid 3 phase disc separator centrifuge for edible oil refinery factory is special equipment for oil and fat refining, it has the traits as high rotating speed, operating stability, completely sealed up of the inlet and outlet system, lower noist and fine separating affection.

Centripetal pump system designed by our professional designer has the traits as stability outlet pressure, large regulating sphere and operating easily.

Also this series separator has professional automatic domination case with safety protection device, advanced automatic vibrating testing instrument can view vibrating testing instrument can view vibrating number at any time.

We can make separating and discharing to the best affection from regulate separting parameter directly at the screen.

Product Principle The disc separator is specially used for the two phase and three phase separation.

The two phase separation is to separate the suspended solid from liquid or separate two liquids which have the different specific gravity and are immiscible.

The three phase separation is to separate the two immiscible liquid phases and a phase of solid at the same time .

Product model list - - - - Model | Flowrate | Inlet pressure | Outlet pressure | Power | Weight | DHZ360 | 1200-2500 LPH | 0.05 MPA | 0.1-0.25 MPA | 7.5 KW | 1280 KG | DHZ470 | 2500-7000 LPH | 0.05 MPA | 0.1-0.25 MPA | 15 KW | 1880 KG | DHZ550A | 5000-10000 LPH | 0.05 MPA | 0.1-0.25 MPA | 18.5 KW | 2200 KG | DHZ550E | 6000-15000 LPH | 0.05 MPA | 0.1-0.25 MPA | 22 KW | 3000KG | DHZ700 | 15000-30000 LPH | 0.1 MPA | 0.2 MPA | 30 KW | 3300KG | DRZ360 | 1200-2500 LPH | 0.05 MPA | 0.1-0.25 MPA | 5.5 KW | 750KG | DRZ400A | 2000-6000 LPH | 0.05 MPA | 0.1-0.3 MPA | 7.5 KW | 1150KG | DRZ400E | 4000-7500 LPH | 0.05 MPA | 0.1-0.3 MPA | 7.5 KW | 1300 KG | DRZ550 | 6000-18000 LPH | 0.05 MPA | 0.1-0.3 MPA | 22 KW | 2200 KG | - - - - Product Application Main application Fields: 1 - Soybean, Rapeseed, sunflower seed, cotton seed 2 - Palm oil, Coconut oil, linseed oil 3 - Peanut, Corn Germ, Rice bran oil 4 - Special oil, such as sesame oil, orange peel oil, safflower oil and so on Core capacity: 1 - Degumming 2 - Deacidification 3 - Dewaxing 4 - Fractionation 5 - Water washing 6 - Squeezed oil clarification 7 - Lecithin deoiling 8 - Frying oil refining Production workshop Our Company employs a team of well-trained professional, adopts advance ERP production management model in-cooperation with state-of-the-art apparatus and processes for manufacturing all kinds of filters, separators, centrifuges amd pumps.

Our service During selection process : 1 - Professional Engineer wil recommend you the most suitable model according to your requirement.

2 - Supply reference process flow chart .

3 - Supply on-site installation and operation test 4 - Integration for control system and process 5 - Customized size and structure After service : 1 - Months guarantee period from machine arriving date.

2 - Sufficient spare parts in stock are available .

3 - Technicians are availabled for overseas service.

4 - 24 hours technical consultation .

5 - The customer could get trained by our experienced tecnician.

6 - Routine tracing will be done timely.

7 - Guide you do the normal maintenance.

8 - Suggestions and any comments &reflection from customer would be treated in priority.

9 - Markting team will visiting if you need.

FAQ 1) Q: How can we visit your factory? A: If you come from abroad, air to shanghai airport, then we can pick you up at airport.

If you come from domestic city, air or train directly to Wuxi station.

We will pick you up at railway station.

2) Q: How do you ensure the quality of your products? A: Our Company is a state owned enterprise with more than 30 years experience, strict operation policy is performed, advanced processing machines guarangtee the precision of all components, workers with operation license, parts get multiprocessing, transmission& electrical parts are of international famous brand.

Series of test and inspection are done in the whole producing state.

3)Q: What payment methods your company accept? A: We accept most of the payment methods, but mainly accept T/T, L/C at sight .

4) Q: How long is the warranty time for your products? A: Our officially promised warranty time is 12 months after commissioning .

5) Q: What's the shipment terms and delivery time of your company? A: Well, the delivery time depend on the quantity of your order.

Usually is 20 days .

For some customized machine 30 days is necessary.

6) Q: Do you give any Discount? A: I will surely try my best to help you get those by the best price and good service at the same time

Company Contact:

• Posted By: Juneng Machinery Co., Ltd.

• Phone: 86-510-87500082

• Address: Chaoyang Road, Zhoutie Town, Yixing City, Jiangsu Province, Yixing , Jiangsu , China

• Email:

• Website: https://www.discseparator.com

• Business Description: Juneng Group is a large scale manufacturer with its subsidiaries namely Juneng Machinery Co., Ltd and Jiangsu Juneng Machinery Co., Ltd.The group principally engaged in the in-house research & development as well as manufacturing of various industrial filters, separators and pumps.
