Hy T50 Co2 Laser Power Supply For Spt C50 Laser Tube With 50w - China

price: 90.00 Dollar US$

Hy T50 Co2 Laser Power Supply For Spt C50 Laser Tube With 50w

Products Photos Catalog T50 Laser Power Spt Photos Catalog

Main features

1) Good compatibility: It can be applicable to 40W and 30W laser tube manufactured by various factories.

2) Quick response speed and good effect: High performance, large cutting power.

It also can prolong laser tube’s service life.

3) Easy Control: The start and stop of laser can be easily controlled by TTL level.

4) The power supply has output open circuit protection.

5) The power supply has TTL signal indication, water through signal indication and laser output indication.

6)This power supply has the BUTTON to test output laser manually.

7) Application: Sculpture and cut acrylic, fabric, double color sheet and rubber, etc.

Specifications

Input Input voltage AC 220V or 110V(please specify when placing order)

AC frequency 47-440HZ

Max input power 350W

Output Max output current 3A

Max output voltage DC 25KV

Max output current DC 20mA

Efficiency >=90%(full load)

MTBF(Mean time between failure) >=10000hours

Response speed <=1ms(from the TTL signal is given to the output current up to 90% of setting current)

Withstand voltage Input-output, input-enclosure: AC1500V 10mA 60s, output cathode is connected with enclosure.

Weight 1.65kg

Environment Operating temperature: -10~40degrees , relative humidity: <=90%

Cooling Force air cooling(FAC)

Dimension L*W*H=167*144*91mm


Company Contact:


  • Phone: 0081-15165137380

  • Address: Lanxiang Road, JINAN , Shandong , China

  • Email: Email


Published date: December 17, 2016 - Modified date: December 17, 2016

  • Business Description: Shandong Laser Source Technology Co., ltd. is the same as Jinan Hongyuan Electric Co., Ltd (China) Jinan Hongyuan Electric Co., Ltd.

    It is a high-tech enterprise, located in the core area of electronically developed regions-Jinan.

    Professional designer & manufacturer & exporter of laser power supply with 15 years experience.

    Have good long - term cooperation with YUEMING laser, HAN'S laser, GCC laser, RECI laser, EFR laser, Boye laser, Beyond laser, Senfeng laser, Bodor laser, SUN-UP laser, etc.

    Hope we will have chance to help you in your business line.



    We produce strictly according to ISO9001: 2008 international quality management system elements of conduct production activities.



    Welcome to our factory!!!
