CNC Hydraulic Punching& Drilling& Marking Machine Model CJ 103, Plate Drilling Machine, Plate Marking machine, Hydraulic Plate Punching Machine

DETAILS

CNC technology with servo motors in X/Y/Z three axes.

Integrated with hydraulic, pneumatic and mechanical elements, which are imported world-class components.

Easy programing- can directly use the program data by sample software.

With function of self-diagnostic for failures.

Displaying the drawing of workpieces.

The machine frame is by C–type plate welding structure.

There are three die-stations.

One of them is marking die-station.

Automatic switching die-stations.

Clamping system can adapt to different workpiece, with zero baffle as datum mark, and workpiece supported by rolling-ball working table.

X & Y axes movements are controlled by servo motor and ball-screw driving.

Double-axis CNC system controls the position of punching to automatically make the whole machine process.

Operator may input the size of workpiece to computer for repeated calling program in the future.

APPLICABLE INDUSTRY:

This machine is used for punching and marking of joint plate in the field of iron tower.

It is also used to punch and mark of metal plate.

ADVANTAGES:

CJ 103 machine is CNC PUNCHING & DRILLING & MARKING FOR PLATES consisting of Plate Punching and Marking Unit, also equip a Drilling unit.

Important functional conponents adopts modular assembly.

It is easy to repair.

Drilling unit has the functions including rapid falling, slow work-feeding and quick feeding back to improve working efficiency.

When editing, only need to input angles size, hole diameters, positions, and quantities by using CAD/CAM directly conversion.

The hydraulic station adopts double pump, single motor, water cooling system, sleeve type coupling for all pipelines.

The glue of hose and coupling (EMB) are exported form Germany.

according to customer requirements.

Hot Sale cnc machine for drilling, punching, milling, shearing, sawing, bending, roll forming, hole processing.

The Machine is used for Plate, Angle, Flange, Connection Boards.
