High Torquqe 12v 30kg Cm Dc Gear Motor Rs 775 With Gearhead 60mm Gearbox Sga 60fm G101i - China

price: 10.00 Dollar US$

High Torquqe 12v 30kg Cm Dc Gear Motor Rs 775 With Gearhead 60mm Gearbox Sga 60fm G101i

Products Photos Catalog Torquqe 12v 30kg Gear Photos Catalog

Model

SGA60FM-G

Rated Volatge

12V

Reduction Ratio

1/334

Gearbox Length

36.5mm

No Load Speed

13rpm

Rated Speed

9.1rpm

Rated Torque

30kg.

cm

Rated Current

2.31A

Motor Dimensions

Check following drawing

Custom

Parameters and shaft

Please let us know the following Parameter if we are lucky to attract your interests:

1 - Voltage & Frequency

2 - Number of revolutions and direction of rotation

3 - Type of output shaft ( Our standard shaft our your customized shaft)

4 - Torque on output shaft

5 - Motor Dimensions if you have your own drawing

The output shaft can be customized variously according to customers'requirements.

Gr eat care should be taken when processing shaft, Motor performance may be affected by heavy radial loading, or external impact, or cutting metal powder.

Operating temperature range

Motor operating temperature range: -10'C+60'C.

All of our technical datas are tested under ambient temperature between 20'C- 25'C.

If motor operated out of above temperature range, lubricating oil can't work and which may cause motor can't work properly.

Operating Humidity range

Do Operate the motor in the humidity range of 20$~85% RH, In the moist environment, motor's metal parts is easy to get rusty, and it may get into malfunction.


Company Contact:


  • Phone: +86 18126006529

  • Address: Zhonggang Road, Shenzhen , Guangdong , China

  • Email: Email


Published date: July 20, 2016

  • Business Description: Shenzhen Songgang Technology Co., Ltd.is one branch of Songgang international group company.

    The headquarters is in Hongkong.

    We have factories both in Taiwan and mainland China, producing kinds of AC motors and DC motors, such as synchronous motor, hysteresis motor(HTS), Dc gear motor, DC brush motor, brushless motor, planetary gear motor, stepper motor.
