Aisi Standard Hot Work Tool Steel H13 Skd61 Quenching And Tempering Machinery - China

1.2344/ H13/ SKD61 Quenching and Tempering Machinery Hot Work Tool Steel - - - - Equivalent Grades | Inrtoduction | GB | DIN | AISI | JIS | ASSAB | H13 is hot work die steel, the implementation of standard GB / T1299-2000 - ; Grade 4Cr5MoSiV1; alloy tool steel referred to as the joint steel, carbon steel is based on the addition of alloying elements and the formation of steel.

Among them, including: measuring tool with cutting tools, impact resistance steel, cold work die steel, hot die steel, non-magnetic die steel, plastic mold steel.

| 4Cr5MoSiV1 | 1.2344 | H13 | SKD61 | 8407 | Available Size (mm) | Flat Bar Size (mm) | Round bar Size(mm) | Thickness | Width | Length | Diameter | Length | 16-260 | 205-610 | 3000-6000 | 16-200 | 3000-6000 | Chemical Composition(%) | C | Si | Mn | P | S | Cr | Mo | V | 0.30-0.40 | 1.20-1.60 | 0.30-0.50 | 0.015 | 0.003 | 3.5-4.5 | 0.80-1.20 | 0.80-1.00 | Recommend Heat Treatment | Quench | Temper | Heating temperature/C | Cooling way | Hardness (HRC) | Tempering temperature | Tempering number | Hardness | First preheating | Second preheating | Last heating | /C | (HRC) | 500-600 | 820-860 | 1010-1060 | Oil Cooling | 53-55 | 560-620 | 2 | 50-47 | 1 - Characteristics | a, High resistance of tempering softenng properties(the using temperanture can improve 50C than that of H13 steel).

| b, Excellent Thermal Stability: Heat preservation in the long time of 620C, the hardness is always higher than that of H13, and still maintain in 35HRC above.

| c, Excellent thermal fatigue resistance: The thermal fatigue resistance is better than that of H13 steel.

| 2 - Applications | Forging die, casting die, hot squeezing die | 3 - Technical service | Die vacuum heat treatment and die surface treatment(N-O, C-N, carburize and nitridation surface treatment).

| 4 - Terms of payment: | 30% deposit T/T and the balance by L/C at sight, or T/T | 5 - Delivery condition: | For abundant stock, 15-20 days.

For customized products, 30-50 days.

| Factory Hardness: Annealing 235 ~ 205 HB, quenching 50 HRC | - - - - Our service Our company have introduced large-sized vertical saw machines, horizontal saw machines, milling machines, grinding machines and other advance equipments, we can export our products by wholesales and retail sales, whole plate or strip is available.

All our products can meet the standards of DIN, AISI, JIS and GB, all the material should be inspected the ultrasonic, hardness and others strict inspection process before the shipment.

a, Sizes, materials and others are all at your requirements and can be changed; b, Price varies on materials, dimensions, finish craft and different payments; c, We are direct manufacture in machinery manufacturing work with experience of several decades; d, Detail production design will be made according to information you offered; e, We have adequate inventory, so that we can quick delivery; f, The most important is that we have advanced equipment.

Company Contact:

• Posted By: Guangzhou Changfeng Steel Co., LTD

• Phone: 86-020-82515856

• Address: Rm B802, Budong Business Building, No. 403 Dashadidong, Huangpu District, Guangzhou, Guangdong, Chin, Guangzhou , Guangdong , China

• Email:

• Website: https://www.hotwork-toolsteel.com

• Business Description: Guangzhou ChangFeng Steel Co., Ltd. is a professional special steel company, which specialized in exporting mould steel products based in China.

  With years experience in special steel industry, our main products are Plastic Mould Steel, Hot Work Mould Steel, Cold Work Mould Steel.
