Pds 3 3cr2mo Plastic Mold Steel Round Bar Diameter 10 350mm Free Samples - China

1.2311/ P20/ PDS-3/ 3Cr2Mo Plastic Mold Steel Round Bar (Diameter 10-350mm) Applications Used for various lager-sized or medium-size precision plastic mould and alloy parts.

a, Ideally suited for the production of plastic moulds; b, Die holders, zinc die casting dies, backers, bolsters and injection moulds; c, Shafts, rails and wear strips; Mechanical Properties - - - - Properties | Metric | Hardness, Brinell (typical) | 300 | Hardness, Rockwell C (typical) | 30 | Tensile strength, ultimate | 965-1030 MPa | Tensile strength, yield | 827-862 MPa | Elongation at break (in 50 mm (2)) | 20.00% | Compressive strength | 862 MPa | Charpy impact (V-Notch) | 27.1-33.9 J | Poissons ratio | 0.27-0.30 | Elastic modulus | 190-210 GPa | - - - - Equivalent Grades - - - - GB | DIN | AISI | JIS | 3Cr2Mo | 1.2311 | P20 | PDS-3 | - - - - Chemical Composition (Wt%) - - - - Steel Grade | C | Si | Mn | Cr | Mo | S | P | 1.2311 | 0.35-0.45 | 0.20-0.40 | 0.60-1.00 | 1.80-2.10 | 0.30-0.55 | 0.003 | 0.030 | P20 | 0.35-0.45 | 0.20-0.40 | 0.60-1.00 | 1.80-2.10 | 0.30-0.55 | 0.003 | 0.030 | PDS-3 | 0.35-0.45 | 0.20-0.40 | 0.60-1.00 | 1.80-2.10 | 0.30-0.55 | 0.003 | 0.030 | - - - - Available Size (mm) - - - - Flat Bar Size(mm) | Round Bar Size(mm) | Thickness | Width | Length | Diameter | Length | 10-700 | 155-2200 | 2000-6000 | 20-200 | 2000-6000 | - - - - Recommend Heat Treatment - - - - Quenching | Tempering | Heating temperature/ | Cooling way | Hardness (HRC) | Heating temperature/ | Cooling way | Hardness (HRC) | 850-880 | Oil Cooling | 50-52 | 580-640 | Air Cooling | 28-32 | - - - - Features a, Good hardness uniformity and polishing property, good machining properties.

b, Good integral machanical performance when under high temperature, high Corrosion resistance c, Good heat-resistance and fatigue-resistance, very high mechanical behavior, cutting mechanical property.

d, Pre-hardened to HRC28-32, can be directly used on mould processing, shorten the construction period.

e, High putity and homogeneous structure of China's biggest ESR production base for its strict requirement in the whole process of exploitation, smelting, vacuum degassing, ESR, forging, annealing, inspection.

Physical Properties of 1.2311 P20 3Cr2Mo Density: 0.284 lb/in3 (7861 kg/m3) Specific Gravity: 7.86 Modulus of Elasticity: 30 x 106 psi (207 GPa) Thermal Conductivity: 24 Btu/ft/hr/F 41.5 W/m/K Machinability: 60-65% of a 1% carbon steel Our service Our company have introduced large-sized vertical saw machines, horizontal saw machines, milling machines, grinding machines and other advance equipments, we can export our products by wholesales and retail sales, whole plate or strip is available.

All our products can meet the standards of DIN, AISI, JIS and GB, all the material should be inspected the ultrasonic, hardness and others strict inspection process before the shipment.

a, Sizes, materials and others are all at your requirements and can be changed; b, Price varies on materials, dimensions, finish craft and different payments; c, We are direct manufacture in machinery manufacturing work with experience of several decades; d, Detail production design will be made according to information you offered; e, We have adequate inventory, so that we can quick delivery; f, The most important is that we have advanced equipment.
