Portable 3a Sanitary Fittings Short Bend Weld Stainless Steel 45 Degree Elbow 1 2 X 0 065 - China

3A StandardTP316L Sanitary Welded Fittings 45 Degree Short Bend Weld Elbow 1/2'' X 0.065'' Features: Spezilla's 3A Standard TP316L Sanitary Welded Fittings 45 Degree Short Bend Weld Elbowis made of type 304 or 316L stainless steel with a 32RA ID/OD finish and has butt weld connections on both ends.

This 45 elbow is used to change flow direction in many applications for the semiconductor, cosmetics, food, dairy and beverage industries.

Our Sanitary Butt Weld Fittings meet or exceed 3-A standards with an ID polish of 180 Grit or 25 Ra on the Inside of the Tube and a 150 Grit or 32 Ra on the Outside of the tube.

Spezilla supplies each Sanitary Butt Weld product with the size and alloy and a heat number for full trace ability for either alloy.

Our Sanitary Butt Weld Fittings are made to close tolerances to permit easy and fast installation of a corrosion resistant, crevice free, fully sanitary process line.

1 - 45 degree Sanitary Short Bend Weld Elbow Fitting.

2 - Stainless Steel 316L.

3 - Certified by 3-A Sanitary 63-03 standards for sanitary fitting.

4 - Polished ID & OD ( Ra<=0.8 um).

5 - Material fully complies with 3-A standard.

6 - Material Test Certificate available with Heat number upon request.

7 - Ship within 1 business day.

Descriptions: - - - - Item Code: | SPF-WE-316L-S45-0025-065- 3A | OD: | 1/2'' | Wall Thickness: | 0.065'' | Material: | TP316L | Standard: | 3A | Finish: | ID/OD POLISHED | Connection Type: | Butt Weld | Certification: | 3A | Mill Test Certificate: | EN10204 3.1 | Packing: | Ends Capped | MOQ: | 1PC | Shipment: | FOB / CIF | - - - - Chemical Compositions: - - - - Elements | 316L (wt%) | C / Max.

| 0.035 | Mn / Max | 2.00 | P / Max | 0.045 | S / Max | 0.005 - 0.017 | Si / Max | 1.00 | Ni | 10.00 - 14.00 | Cr | 16.00 - 18.00 | Mo | N/A | Fe | Bal.

| Cu | N/A | N | N/A | - - - - Mechanical Properties: - - - - Grade | Tensile Strength (Mpa) | Yield Strength (Mpa) | Elongation (%) | Hardness (HRB) | 316L | 485 | 170 | 35 | 90 | - - - - Quality Assurance: 1 - Material Controlled & Machined Precisely.

2 - Easily welded 3 - Quickly fit up 4 - High corrosion resistant 5 - Long service life 6 - Safety Stock System.

7 - Well packaged 8 - Fast delivered 9 - Surface Finish: #180 Grit, #320 Grit Applications: Spezilla'sstainless steel sanitary fittings are applicable to a wide range of manufacturing industries: 1 - Food & Beverage 2 - Dairy 3 - Wine & Brewery 4 - Cosmetic 5 - Pharmacy 6 - Biotechnology
