Prestressing Strand Unbonded - China

Prestressing Strand Features

Prestressing Strand Huayongxin (also referred to as Prestressed Concrete Steel Strand), is made from the stranding of seven wires of high carbon steel wire rod, and mainly used as auxiliary reinforcing strand for concrete structures.

It has the following characteristics and advantages:

High tensile strength and low relaxation

Higher fatigue, higher breaking loads and corrosion resistance

Better performance at elevated temperature

Stable modulus of elasticity

High bonding force

Reduce distortion and construction weight

Established in 2004 in Tianjin, close to Tianjin port, Huayongxin cover an area of 120, 000sqm, have 4 workshops, 2 laboratories, 8 PC wire production lines and 4 PC strand production lines with each line production capacity at 3000 tons per month.

PRODUCT PROPERTIES

Prestressing Strand Properties

Product Name Prestressing Strand Huayongxin

Type Bonded & Unbonded

Materials SWRH82B

Diameter 1x7 Wire 9.53mm, 12.7mm, 15.24mm

Tensile Strength 1860Mpa

Relaxation (%) ≤2.5

Elongation (%) ≥3.5

Standard ASTM A 416, GB/T5224-2003, BS5896, JISG3536-88

Coil Dimension & Weight Inner Diameter: 800m

Outer Diameter: 1400mm

Width: 750mm

Coil Weight: 2.5-3.2MT/Coil

Packing Coils wrapped by 8 steel strips → Fully wrapped with waterproof & P.

P woven sheet → Fixed with wooden pallet → Strapped at 8 places with steel strips

Prestressing Strand Application Prestressing Strand is mainly used in prestressed and post-tension concrete structure, such as post-tension slab, large-span bridges on railway and highway, overhead crane beam, prefabricated bridge girder, multi-storey industrial buildings, stadiums, rock-soil anchoring project, coal mines, etc.

HUAYONGXIN Our Advantages Extensive experience in exporting.

Professional team to manage production and control product quality.

Three rust-preventive measures taken to guarantee no rust caused.

Special designed wooden pallet used to avoid any damage to the container during offloading.

Equipped with advanced testing facilities and abide by the principle of testing each coil produced.
