Titanium Plate Flange - China

1 - Introduction Titanium welding Flange

Titanium Lap Joint flanges

Titanium threaded flange

2 - Materials & standards Material Gr1, Gr2, Gr3, Gr4, GR5, Gr7, Gr9, Gr11

Standard ANSI6.5, STM B16.5, SMEB16.47, ISB2220, IN2627-2628, AWWA, ASTMA182, ASME SA182

size 1/2"~ 60"NB NPS 1/2 - NPS 24 (DN 10 - 2000)

Pressure PN0.25~32Mpa (DIN) PN6 PN10 PN16 PN25 though PN250 150# 250# 300# 400# 500# 600# 900# 1500# 2500#

Technique Forged and CNC Machined

type Weld necks, Slip-Ons, Threaded Blind, Socket weld, Lap-Joint

surface FF RF TG RJ MFM

States (M) Annealed

Technology Casting, Forging, Cutting, Rolling and CNC Machining

3 - Chemical Requirements Grade N C H Fe O Al V Pa Mo Ni Ti

GR 1 0.03 0.08 0.015 0.20 0.18 / / / / / bal

GR 2 0.03 0.08 0.015 0.30 0.25 / / / / / bal

GR 5 0.05 0.08 0.015 0.40 0.20 5.5~6.75 3.5~4.5 / / / bal

GR 7 0.03 0.08 0.015 0.30 0.25 / / 0.12~0.25 / / bal

GR 9 0.03 0.08 0.015 0.25 0.15 2.5~3.5 2.0~3.0 / / / bal

GR 12 0.03 0.08 0.015 0.30 0.25 / / / 0.2~0.4 0.6~0.9 bal

4 - Physical Properties

Grade State Tensile strength(min) Yeild strength (min) Elongation (%) Ksi MPa ksi MPa GR 1 (M)Annealed 35 240 20 138 24

GR 2 (M)Annealed 50 345 40 275 20

GR 5 (M)Annealed 130 895 120 828 10

GR 7 (M)Annealed 50 345 40 275 20

GR 9 (M)Annealed 90 620 70 438 15

GR 12 (M)Annealed 70 438 50 345 18

Company Contact:

• Posted By: Superbti Co.,Ltd

• Phone: +8615529476368

• Address: Xuguang Industrial Zone,Hi-tech Development District, , Baoji , shaanxi , China

• Email:

• Website: https://www.superbti.com/

• Business Description: Superbti is one of Asian leading suppliers of high performance titanium base in China, specializing in mill and melted products, such as titanium bars, wire, plates, forgings, tubes and fasteners.

  Superbti has a fully integrated supply chain, dedicated research facilities, and decades of experience which make us the partner of choice when it comes to titanium.
