Hot Press Machine For Commercial Plywood Marine - China

15 Layers Hot Press Machine for Commercial Plywood Marine Plywood

Technical Specification: Model No.

BY214x8/60-15

Hot Platen Size 1370x2700x42/52mm

No.

of Layers 15 Layers

No.

of Hot Platens 16 pcs

Layer Opening 70 mm

Main Cylinder Diameter φ360mm

Main Cylinder Stroke 1050 mm

Main Cylinder No.

2 sets

Quick Close Cylinder Diameter φ180 mm

Quick Close Cylinder No.

1 set

Close Time 12s

Oil Circuit Direction Double inlet double outlet

Heating Medium Steam Water/Thermal Oil

Nominate Pressure 6000 KN

Rated Hydraulic Pressure 25 Mpa

Hydraulic Pump Type Aviation Pump

Dimension 3340x1400x4100 mm

Weight 28500 kg

Key Features:

1 - Widely Used: This 15 layers hot press is widely used in making construction plywood, decorative plywood, packing plywood, marine plywood, LVL plywood, blockboard etc.

2 - High Accuracy Hot Platens: In order to control the quality of the hot platens, we bought the complete line of machines for making hot platens, including the lathing machine, drilling machine, milling machine, boring machine.

Now all the hot platens are made by ourself.

The platens are flat, smooth, and thickness error less than 0.05mm at different positions.

3 - Oil/Steam Water Circuit: This hot press machine is double inlet and double outlet circuit, so the hot platens can be heated up soon, 4 - Temperature Control System: We add the flow-valve on each layers and circulating pump to control the temperature, and the temperature will be same on different layers and will be constant at different time.

5 - Automatic Control System: Omron PLC is applied to control the hot press machine automatically, and you can also choose to use the Manual Control model if you need.

6 - Quick Close System: We use a lift cylinder on this press machine, and the close speed will be faster and will take less time working efficiency will be higher.

7 - Cylinder Origin: All the cylinders we use are from Wuxi China, the best cylinders in china, it is more durable and need less maintenance.

8 - Pump and Hydraulic Components: We use the aviation pump on this machine and all hydraulic components are from Shanghai which use the Japanese technology.

9 - Strong Structure: All the side frame, beam, upper cover, bottom base are made of thick steel 30mm/40 mm, strong enough to support this pressure .

10 - Customized: Hot press with different size are available, size 4x8ft, 3x6ft, 5x5ft, Pressure: 400Tons, 500Tons, 600Tons, 800Tons, Hot platen thickness 42mm, 52mm, 60mm, 80mm, all available
