Sfp 4 25gbps 850nm Series Optical Module - China

Features l Operating Data Rate up to 4.25Gbps l Single 3.3V Power Supply and CML Logic Interface l 850nm VESCL transmitter and high performance PIN receiver l Link Distance up to 300m with 50/125µm multi-mode fiber l Low EMI and excellent ESD protection l Built-in Digital Diagnostic Monitoring (DDM) function, Compliant with SFF-8472 l Operating Case Temperature Standard(C): 0℃~+70℃ l Industrial(I): -40℃~+85℃ Applications l 1.063/2.125/4.25Gbps Fiber Channel l Other optical Links General The GIGAC's GACS-8548-02x series is a multi-rate 850nm SFP which ensures compliance to 4.25Gbps Fibre Channel specifications without the need for Rate Select.

mode transceiver is small form factor pluggable module for serial optical data communications such as IEEE 802.3ae .

It is with the SFP 20-pin connector to allow hot plug capability.

This module is designed for multi-mode fiber and operates at a nominal wavelength of 850nm.

The transmitter section uses a 850nm VCSEL laser and is a class 1 laser compliant according to International Safety Standard IEC-60825.

Company Contact:

• Posted By: Gigac

• Phone: +86.18512845338

• Address: Zone 3-502,Haolang Science Park, Chengdu , Sichuan , China

• Email:

• Website: https://www.gigac.com/

• Business Description: Gigac Technology Co., Ltd.It was established in May 2012, which is focus on the Fiber Optical Transceivers Modules and devoted to be the leader of optical transceivers manufacturer in China.

  The Headoffice is in Chengdu city,China.

  It is composed by Operation Center, Sales Center, Research and Design Center, Labratory, Production Line and branch offices in Beijing, Nanjing, Wuhan and Shenzhen.

  GIGAC has implemented ISO9001: 2008 Quality Management System and ISO14001: 2004 Environmental Management System.

  Whole Supplying Chain and Production Line are complying with RoHS6 standard, FCC, CE and other compulsory certification system associated with fiber optic industry.

  With more than 10 years of producing and researching experience, Gigac has developed many variants of optical modules: Full Scale Production from 100M to 1.25G and 10G Bit Rate, release EPON,GPON and 40G in 2013, release 40G QSFP+SR modules in 2014, release SNAP 12 Parellel, UOST/Stratos series, T/R Component in 2015, Release QSFP28 SR, LR4 ,CWDM 4 in 2017 - Now SFP+ 120KM transceivers, GPON, EPON, XGSPON,Combo series are released.
