Dwdm Solution For Long Distance 40g Network - China
price: 8000.00 Dollar US$
Background
The amount of data accumulated today by users and enterprises is vast, and keeps growing.
Consequently, storing and accessing this data have also become more demanding, requiring higher data capacity and data transport over longer distances.
One of our customers is looking at adding DWDM system for existing 40G Network as a future technology in a more serious way.
Challenge
The storage infrastructure in data centers today are equipped with 10G and 40G switches.
Increasing the transmission distance of the network is challenging especially for 40G, as the maximum reach of 40G QSFP+ optics is limited to 40 km and each 40G interface needs a dedicated fiber between sites, leaving a gap for data centers to fill.
The customer network has a dark fiber linking two sites beyond 40km, and they barely know the link loss between these sites.
Solution
With a relatively large link budget, this solution helps boost 80G data reach up to 60km without the need to place additional fiber.
In this way, one 40G optical signal can be broken out into 4x10G signals, and then the OEO converts them into the corresponding DWDM wavelengths.
If adding dispersion conpensation modules and amplifiers, the link distance can be more than 60km.
For example, even 80km is possible.
As DWDM 10G 80km transceiver is utilized for data transmission, we use the attenuator to adjust the Rx power of optical transceiver in the range of -13dBm~-20dBm to avoid burning the transceiver.
The booster amplifier (BA) is deployed behind the optical transmitter MUX while in front of the optical fiber line to increase the power of the transmitted light.
The pre-amplifier (PA) is placed before the optical receiver Mux but after the optical fiber line to amplify the weak optical signal.
DWDM solution
Customer Benefits
A cost-effective 40GbE solution is a key enabler for delivering support for higher bandwidth flows and lower latency.
HTF 40G network solution enables the use of inexpensive and simple 10Gb DWDM systems to extend a 40GbE service, avoiding the need for new hardware or for an entirely new cabling infrastructure, providing a significant investment protection.
HTF can help you design coherent 400G/200G/100G DWDM/OTN solution, DWDM Single lamda 100G/200G/400G Dual fiber/Single fiber Ultra long distance transmission.
Company Contact:
- Posted By: Shenzhen htfuture Co., Ltd
- Phone: +8675523777185
- Address: 8819 , Shenzhen , Guangdong , China
- Email:
- Website: https://www.htfuture.com
Published date: January 8, 2024
- Business Description: Shenzhen htfuture Co., Ltd is a professional supplier of fiber optic products and WDM systematic solution.
Was built by a team who has more than 10-year experiences in optical communication product R&D, fiber solution, component developing and manufacturing.
HTFuture supplies a broad range of communication solutions products including wavelength division multiplexer(WDM/CWDM/DWDM /OADM), Fiber Optic Transceivers(SFP, SFP+, XFP, 10G QSFP+, 40G QSFP+ and 100G CFP2), OEO Converter Repeater, Ethernet Media Converter, Fiber Optical Patch cord and Fiber Optical assembly.
Currently our products are widely used in Telecommunication, CATV, FTTX, WANs, LAN, Gigabit&10 G Ethernet, SDH/SONET, Fiber Channel, Roadway safety, Data-video Transmission, Long-distance monitoring, Military and many other fields.
The aim of HTFuture is provide you quality products, gratified service and fast delivery.
