Excellent Brocade Compatible 10gbase Zr Xenpak 1550nm 80km Transceiver - China

price: 1000.00 Dollar US$

Excellent Brocade Compatible 10gbase Zr Xenpak 1550nm 80km Transceiver

Products Photos Catalog Brocade Compatible Photos Catalog

WXK-15192-ES80D

10Gb/s XENPAK ZR Transceiver

Hot Pluggable, Duplex SC, +3.3V, 1550nm, Cooled EA-DFB SMF 80KM DDM

DESCRIPTION

WAREX's WXK-15192-ES80D is a highly integrated, Serial optical transponder module for high-speed, 10Gbit/s data transmission applications.

4×3.125Gbps Ethernet Signal Input by XAUI Interface.

An integrated Coder / Decoder and multiplexer / demultiplexer (SERDES: Serializer / Deserializer).

Designing for 10GBASE-ZR Transmission with an uncooled directly modulated 1550nm Cooled EA-DFB Laser.

The transponder operates within a wide case temperature range of 0°C to +70°C and offers optimum heat dissipation and excellent electromagnetic shielding which enables high port densities for 10 GbE systems.

A 70 pin electrical connector and a duplex SC connector optical interface assure that connectivity is compliant to the XENPAK MSA Rev.

3.0 - FEATURES

XENPAK MSA Compliant

70-PIN connector

SC duplex receptacle package

XAUI 4x3.125Gb/s and TX/RX 10Gb/s data rate

Cooled EA-DFB/APD

Power supply: +5.0 V, +3.3 V, APS: +1.2 V

Power Dissipation 4W Maximum

0ºC to 70ºC Operating Case Temperature

Digital Diagnostic Monitoring

Management and control with MDIO 2-wire bus

XAUI electrical interface 4 x 3.125 Gb/s Ethernet

≤80km ZR 10GBE

RoHS compliant and lead free

APPLICATIONS

10GE Ethernet switches and routers

10GE Core-routers

10GE Storage

Other 10Gbps Ethernet Transmission System

Absolute Maximum Ratings

Parameter Symbol Min Max Unit

Supply Voltage+5V Vcc5 0 6.0 V

Supply Voltage_3.3V Vcc3 0 4 V

Supply Voltage APS Vaps 0 2 V

Storage Temperature Tst -20 85 ºC

Optical Input Received Power APD - -7 dBm

Any stress beyond the maximum ratings can result in permanent damage.

The device specifications are guaranteed only under the recommended operating conditions.
