Linkreal Four Lane Pcie 4 Port M 2 Sata 3 0 Adapter With Marvell Chipset 88se9215 - China

price: 23.50 Dollar US$

Linkreal Four Lane Pcie 4 Port M 2 Sata 3 0 Adapter With Marvell Chipset 88se9215

Products Photos Catalog Linkreal Lane Pcie Photos Catalog

This PCIe SATA controller card has two SATA channels that can be independently switched between the internal or external (eSATA) ports as needed.

This versatile add-in card offers SATA III connectivity (6Gbps), while remaining backward compatible with SATA I (1.5Gbps) and II (3Gbps) device connections, which helps eliminate the expense of having to upgrade drives.

It supports M.

2 B Key SATA SSD in Size 2230, 2242, 2260 and 2280 - Mode: LRST9615-2M2S

I/O Controller: MARVELL 88SE9215

Bus Type: PCI Express 2.0

Compatible Drive Type: 4 SATA SSDs

Interface: 2*M.

2&2*SATA

Drive Connector: 2*M.

2&2*SATA

Host Connector: PCIe x4

Humidity: 0% – 90%

Operating Temperature: 0°C to 50°C (32°F to 122°F)

Storage Temperature: -10°C to 65°C (14°F to 149°F)

Dimension: 136mm*69mm

Product Weight: 170g

Warranty: 2 Years


Company Contact:


  • Phone: 13297443840

  • Address: Building C5, Xintang Industrial Zone, Baishixia, Fuyong Town, Baoan District, Shenzhen, Shenzhen , Guangdong , China

  • Email: Email


Published date: March 31, 2020

  • Business Description: Established in 2012, Shenzhen Lianrui Information Technology Co.

    Ltd, also known as Linkreal, is a material production, product development, sale, service set in one-scale enterprise.

    Since our founding in Shenzhen, Linkreal has become a Sci-Tech enterprise expertizing in computer storage and I/O Interface solutions.

    Our products include Computer Backplane, RAID card, NVME card, adapter card, expansion card, JBOD/JBOF, etc.

    They are widely used in fields of Computer, Server, Data Storage, Industrial control and Automatic equipment.

    The products have earned official accreditation of ISO9001 Quality Management System, FCC, CE, RoHS and the like.
