Hcipc P131 3 Adddip 150a 150w Dc Atx Industiral Powersupply - China

price: contact company for price

◆ Dimensions (MM): L156 × W44.8 × H17

◆ Input voltage: +18 V / DC - +24 V / DC

◆ Output Power: 130W

◆ Efficiency: > = 92%

◆ Operating temperature: 0 ℃ ~ 40 ℃

◆ Storage Temperature: -20 ℃ ~ 80 ℃

◆ Output electrical characteristic Votage Min(V) Max(V) Min(A) Max(A) Ripple(mV) Line SCP

+12V 11.40 12.60 0 6 120MAX yellow SPS-down

+5V 4.75 5.25 0 6 50MAX red SPS-down

-12V -11.40 -12.60 0 0.1 240MAX blue NON

+3.3V 3.14 3.47 0 6 50MAX orange SPS-down

+5VSB 4.75 5.25 0 1 50MAX Purple SPS-down Unit: mm Main Features: 4-1 - Temperature: Operating temperature: 0 OC to +40 OC Storage temperature: -20 OC to +80 OC 4-2 - Humidity: Operating Humidity: 0% TO 85% Storage Humidity: 10% TO 90% 4-3 - Input and output voltage: Input: 18V/DC ~ 25V/DC (input over-voltage, under voltage protection) Output Voltage: Standard ATX voltage output (+12 V, +5 V, -12V, +3.3 V, +5 VSB) 4-4 - Power: In 18V/DC ~ 25V/DC voltage input of 100% load conditions, the power MAX130W 4-5 - Efficiency: In 18V/DC ~ 25V/DC voltage input of 100% load conditions, the efficiency of ≥ 92% 4-6 - Dimensions: 155.8mm * 44.8mm * 22.0mm 4-7 - PCB sizes and materials: PCB size is 155.8mm * 44.8mm * 1.6mm PCB material is FR-4, copper thickness 2Oz, double-layer panel board 4-8 - Weight: Product weight: 93.0 ± 1 G 5 - Electrical Testing 5-1 - Electrical Description Products for the DC-DC 130W DC power supply, the output of 5 groups, mainly for MINIPC, POS machine systems, +5 VSB to control the voltage, other voltage controlled input voltage and "PS-ON" signal 5-2.Testing Specification Model Output Min(V) Max (V) Slight(A) Heavy

MAX(A) Wave(mV) Cable color Short-circuit protection AD24P150A +12V 11.40 12.60 0 6 120MAX Yellow Yes

+5V 4.75 5.25 0 6 50MAX Red Yes

-12V -10.80 -13.20 0 0.1 120MAX Brown No

+3.3V 3.14 3.47 0 6 50MAX Orange Yes

+5VSB 4.75 5.25 0 1 50MAX Purple Yes


Company Contact:


  • Phone: 86-755-84565646

  • Address: 607,6F,No.G Building607,6F,No.G Building,LiHao Industiral Park,No.78 AiNan Road,Longgang District, Shenzhen , Guangdong , China

  • Email: Email

Published date: November 6, 2018

  • Business Description: ShenZhen HeCheng IPC Technology Co.

    Ltd ( ABB: HCIPC) is located in ShenZhen, China.

    We are integrated selling and developing for industrial motherboard, industrial pc, network firewall, service etc, HCIPC is high technology company.



    The Main products :

    Embedded Motherboard(EPIC, 3.5INCH, PC-104, ETX, NUC, NANO-ITX, MINI-ITX etc)

    Industrial motherboard (MINI-ITX, ATX NVR MB,Full CPU card etc.



    Network Security motherboard(4LAN,6LAN , 8LAN, FSP etc.



    OEM/ODM

    Industr ial PC (4U industrial PC, wall-mounted industrial PC, multi-serial industrial PC, etc.

    )

    Embedded industrial PC/BOX industrial PC (fanless industrial PC, reinforced fanless industrial PC, three-proof industrial PC, etc.

    )

    Industrial tablet / industrial one machine (resistance screen / capacitive screen, embedded / shelf type 8.4 inch ~ 21.5 inch, etc.

    )

    Industrial display (touch / normal, embedded / shelf type 8.4 inch ~ 21.5 inch, etc.

    )

    Integrated workstation (4U, 8U, etc.

    )

    Industrial portable machine

    Network security Server (19-inch 1U standard, 1U portable, mini fanless, etc.

    )

    Chassis/machine OEM/ODM service

    HCIPC is committed to creating high-reliability and trustworthy intelligent industrial PC hardware for industry users.

    The own brand “HCIPC” products are widely used for industrial automation, communication, power, network security, intelligent transportation, video surveillance, medical care, military / aerospace, self-service terminals, data storage, digital signage, car computers and many other fields, products are exported to the Americas, Europe, Southeast Asia and other regions.

    HCIPC adhere to the quality of survival, innovation and development, HCIPC wish to do win-win business with customers together, and steadily move forward on the road of industrial products in China, and wish create brilliant feature in the world.
