Industrial Panel 8 Inch Lcd Monitor 1024x768 With Touch Screen Vga Idm 08 - China

Anxin Intelligent provides 7", 8"~22 inch Industrial LCD monitors model NO.

IDM-07, IDM-08, IDM-12, IDM-15, IDM-17, IDM-19, IDM-22 - IDM-08 8" Industrial LCD Panel Monitor with VGA input

IDM-08T 8" Industrial LCD Panel Monitor with VGA input, with touch screen and USB controller 8" LCD 1024x768 Industrial panel monitor with touchscreen

8" XGA TFT LCD Panel support 1024x768 pixels, 350 cd/m2 brightnesss

6mm Aluminum front bezel with strengthen glass

Rugged construction and slim modularized design

Input signal : VGA

OSD control keys to optimize the display

AC 100-240V wide range external ac adapter

Panel ( Flush ) mount with bracket

NEMA4 / IP 65 compliant front panel

Meet standard VESA hole ( 100x100 mm ), support desk top stand / wall mount/ swing arm mounting

8" touch panel monitor IDM-08

Display

Display Type 8" XGA TFT LCD

Resolution 1024x768

Max.

color 16.7M

Luminance 350 cd/m2

View Angle 110°(H), 120°(V)

Pixel Pitch 0.15825×0.15825mm

Contrast Ratio 700 : 1

Response Time 8 ms

LCD MTBF 50, 000hrs

Input Signals

RGB Signal D-SUB 15P Connector (female)

DC input DC Jack (2.1mm)

Touch screen USB (option) USB-A type connector (female)

Available Options

Touch screen Resistive Type with USB and RS232 controller

DC Power Input Wide Range 8~30v DC input

AV input No

Power supply

Standard 100~240VAC, 50/60Hz, DC12V@ 5A / 60W, external ac adapter

DC-DC Power DC 8 ~ 30v input power module(optional)

Environmental

Construction Heavy duty steel and aluminum front panel

Operate temperature 0 °C to 50 °C

Storage temperature -20 °C to 60 °C

Storage humidity 10% to 90% non-condensing

Anti-Vibration 17HZ-500 HZ 1G PTP

Anti-Shock 1G / peak( 11m sec)

Packing info

Dimensions (WxHxD) 287.5 x 231 x 50 mm

Weight Net: 3 - kg, Gross: 4.5 kg
