Digital Universal Hardness Tester Uht 900d - China

Features

● ● UHT-900D is a universal hardness testing instrument for the measurement of Brinell, Rockwell and Vickers scale.

● Equip 7-testing-foce and 5-indenter, it is universal to measure a most of metal material.

● Dwell time from 2 to 60S can be setup by the “time key” inside the LCD panel, it is much convenient than the setup on the manual hardness tester.

● Loading, dwell and unloading is driven by electronic motor automatically, doesn’t need the operator to handle it, it eliminates the human operating error maximum.

● Doesn’t need the operator to read and check the hardness scale table, it will compute and display the testing result once press the key of digital length sensor.

Technical specifications：

Model No UHT-900D

Rockwell Scales HRA, HRB, HRC

Rockwell Testing Force 60Kgf(588.4N), 100Kgf(980.7N), 150Kgf(1471N)

Brinell Scales HBW1/30, HBW2.5/62.5, HBW10/100, HBW2.5/187.5

Brinell Testing Force 31.25Kgf(306.5N), 62.5Kgf(612.9N, 187.5Kgf(1839N)

Vickers Scales HV 30, HV100

Vickers Testing Force 30Kgf(294.2N), 100Kgf(980.7N)

Rockwell Hardness Indication Digital LCD display

Rockwell Resolution 0.1HR

Loading Control Automatic

Data Output RS 232/Printer

Magnification of Microscope Brinell: 37.5x; Viceers: 75x

Dwell Time 2~60s

Max.

Height Of Specimen Rockwell: 170mm; Brinell, Vickers: 140mm

Instrument Throat 165mm

Dimension(LxWxH) 520 x215 x700mm

Packing Dimension 630 x440 x960mm

Gross/Net Weight 120Kg/90Kg

Execution Standard EN-ISO 6508, ASTME-18

Standard accesory：

Hardness Block (57-70)HRC

1SET Ø5mm Brinell Ball Indenter 1PC Mini-Printer 1PC

Hardness Block (20-33)HRC 1PC Rockwell Cone Diamond Indenter 1PC 2.5x Brinell Objective 1PC

Hardness Block (85-100)HRB 1PC Vickers Indenter 1PC 5x Vickers Objective 1PC

Vickers Hardness Block HV 30 1PC Ø 150mm Flat Anvil 1PC Power Cable 1PC

HBW2.5/187.5 Hardness Block 1PC Ø 55mm V-shape Anvil 1PC Accessories Box 1PC

Ø1.588mm Rockwell Ball Indenter 1PC Ø 55mm Flat Anvil 1PC Instrument Manual 1PC

Ø2.5mm Brinell Ball Indenter 1PC 15x analogue Eyepiece 1PC
