Lab Organic Solvents Spray Dryer - China

YC-015A Lab scale spray dryer is equipped with inert loop system to handle organic solvents safely.

Furthermore, it conserves resources and environment due to its functional principle, it can be used to dry the samples of aqueous solutions and organic solvents.

It assembles many of new designs, for example, small shape for free moving, combining air compressor and electrical heater inside the cabinet, sight glass for inspecting.

PLC controller with English operation interface.

Safe:

Drying organic solvents safely with inert loop system

Explosion free Spray Drying due to inert gas atmosphere

The prevention of explosion due to oxygen and pressure control

Environmentally sustainable

Organic solvent recovery system with cooling circuit (water-cooling or DLSB-20～-40°C optional )

Closed loop design approaching minimizes pollution and protecting the environment

YC-015A Lab scale spray dryer is popular in field of Food, biology, material, pharm acy enterprise or university, R&D institute.

YC-015A Lab scale spray dryer parameters:

Max capacity: 1500ml/h

Temperature range of Inlet air: 40℃ -200℃

Temperature range of outlet air: 40℃ -140℃

Precision of temperature: ± 1 ℃

Dryer time: 1.0-1.5 S

Speed of squirt pump: 50-1500ml/h, Spray system: two liquid nozzle (0.5/0.7/1.0/1.5/2.0/2.5m m)

Spray direction: downwards co-current

Drying capacity not less than 1.5 liter / h for aqueous solutions and organic solvents.

Dimensions of the dry molecules range from 1-28 µm at least

Can be used to process the samples of aqueous solutions and organic solvents.

The device has system to intensify and separate of organic solvents (Inert loop spray drying with organic solvents).

Digital LCD shows all the processes the device does.

Sensors to monitor the device work, the gas, the heating, the pressure and other.

Automatic de-blocking device prevents the nozzle from becoming blocked and variably controlled.

Using proface touchable interface display operation, operator can control temperature, airflow volume, air pressure, pump speed and de-blocker frequency.
