Automatic Electric Digital Wrap Reel Tester - China

Automatic electric digital wrap reel tester for accurately measuring the length of the yarn Structure principle:

1, the real single-chip domination, mature and reliable electrical circuits: start and stop smoothly, low noise, accurate loop-counting, no loop-clashing phenomenon, Good reliability low failure rate.

2, SCM design as one of the electronic counter

3, with the real-time speed measurement function

4, continuous variable speed

5, can set the final stop early deceleration, smoothly stop rotating, greatly avoiding the phenomenon of loop-clash

6, the sensor dynamic measurement, LED display Main Specifications:

1, can be swirled only count: 1 ~ 6 tube

2, yarn frame circumference: 1000mm ± 1mm

3, yarn frame speed: 30r / min ~ 260r / min (Promise speed)

4, yarn frame laps set range: 2 ~ 9999 circle

5, swinging traverse reciprocating stroke: 35mm ± 0.5mm

6, a single yarn tension range: 0cN ~ 100cN

7, Tension test method: dynamic sensor measurement, digital display

8, 1 to 5 laps ahead of time to stop the slow setting, stop rotating smoothly, no skidding, punching phenomenon

9, SCM design as one of the electronic counter

10, all LCD display, no wear and tear

11, motor power: 60W

12, the power supply voltage: AC220V, 50HZ

13, Dimensions: 780mm × 660mm × 480mm

14, equipment weight: about 45Kg Features Function:

1, design of the overall structure is firm, and adopt the stainless steel and aluminum alloy material, long life and good stability.

2, with the need to install pre-tension device to improve the accuracy of unit testing .

3, with the pre-set fixed length winding wire counter, easy to use.

4, can be equipped with pressure dust cover, to prevent dust and protect the operation to avoid the scruples of clip injuries.

5, equipped with emergency safety switch.
