Building Materials Flammability Tester - China

Building Materials Flammability Tester single-flame source test apparatus Ignitability tester Application Building Materials Flammability Tester single-flame source test apparatus Ignitability tester is used to quickly and accurately detect the resistance and efficiency performance of various flat materials, such as glass fiber, PTFE, PET, PP melt-blown composite filter materials.

Product design conforms to many domestic and foreign industry standards such as EN1822-3: 2012, GB19083-2003, GB2626-2019 (KN95), IEST-RP-CC021.1 - 2 - Standard BS 476-5 "Test Method for Flammability of Building Materials".

4 - Equipment structure 4.1 The structure of the machine consists of a combustion chamber and a control cabinet.

4.2 Burning chamber size: L700 * W400 * H810 (mm) 4.3 Chassis material: The combustion chamber body is made of high quality steel plate, CNC machine tool is formed and the arc shape is beautiful and generous.

4.4 The control cabinet is made of high-quality electrostatic steel plate, and the surface is sprayed with plastic, which is more bright and beautiful.

4.5 Blowtorch: Made by our company, brass material, fully meet the requirements of GB/T8626 standard.

4.6 Other mechanical parts are made of high quality stainless steel or A3 thick plated, anti-corrosion and anti-rust.

5 - Conditions of use 5.1 The ground is flat, well ventilated and free of flammable, explosive, corrosive gases and dust.

5.2 There is no strong electromagnetic radiation source nearby.

5.3 There is adequate maintenance space around the equipment.

5.4 Temperature: 25℃ ~ 35℃.

5.5 AC220V/50HZ.

5.6 Voltage allowable fluctuation range: 220V±10%.

5.7 Frequency allowable fluctuation range: 50Hz±1%.

5.8 The user is required to configure the air and gas source of the corresponding capacity for the equipment at the installation site, and the power supply must be provided separately for the equipment.

PS: (WLJCDM809)
