Fabric Vertical Multi Functional Combustion Tester - China

ISO textile combustion tester, fabric vertical multi-functional combustion tester ISO Textile Flammability Tester

It is suitable for testing the flammability of vertical vertical textiles and components by igniting the edges and bottom edges, as well as testing the flammability of fabrics and fabric combinations for sleepwear, curtains and drapes, and protective clothing fabrics.

ISO textile burning tester, fabric vertical multi-functional burning tester

Symbol GB/T8745, GB/T8746, GB/T5456

ISO6940：1995 vertical vertical specimen flammability performance

ISO6940：2004 vertical vertical specimen flammability

ISO6941：2003 vertical vertical specimen flame spread performance

ISO10047：1993 Fabric surface burning time determination ISO15025：2002 Thermal insulation and flame retardant properties of protective clothing

BS5438：1976 Flame resistance of vertical vertical textiles and components

BS5438：1989 Fire retardancy of vertical vertical textiles and components at bottom edge and edge ignition

BS5722: 1991 Flame retardancy of fabrics and fabric combinations for sleepwear

BSEN1103: 2005 Flammability of fabrics for clothing

BSEN13772: 2003 Flame spread performance of curtains and drapes

AS2755.1, 2, 3 Australia and New Zealand vertical vertical specimens flammability performance and other requirements.

ISO textile burning tester, fabric vertical multi-functional burning tester technical parameters

1, Floor stand, no need to put on the operating table, convenient for the operator to use 2, large combustion rack, can hang a variety of test needle frame, to meet the needs of different testing standards 3, Equipped with 7 kinds of test needle frames and 1 set of stainless steel sample clamps to meet the testing standards of various countries 4, Roller screw to adjust the burner forward and backward, burner height can be adjusted by knob 5, One-touch ignition method, using electric spark ignition 6, Gas: butane and propane combustion gas (user-provided) can be programmed to switch 7, Flame angle indicator panel can show the operating angle 8, the host comes with a flame height measuring tape, detecting the vertical flame height 9, stepper motor drive mode, can drive the burner movement 10, Ignition device angle accuracy of 0.18 degrees, positioning 11, the host adopts outdoor operation mode, can protect the safety of testers 12, Support arm system, can rotate and adjust the control box, easy to operate 13, Touch screen operation mode, easy to use for the operator 14, Human-machine interface and PLC control mode, prefabricated testing standards of various countries Relat:

textile combustion tester kit

textile combustion tester fluid email: market@qinsun-lab.

c om

Qinsun Instruments Co., Ltd

PS: (WLJCDM809)
