Fdr 0531 Motor Gasoline And Aviation Fuel Gum Analyzer - China

Scope

Motor gasoline and aviation fuel gum analyzer is based T8019 ISO6246 ASTM D381 standard GB / design and manufacture.

For the determination of motor gasoline, aviation gasoline, for the preparation of volatile fractions and aviation turbine fuel in the car when the gum and trials unwashed gum content of gasoline.

This product uses the sub-structure, from the main chassis and control box.

The main chassis evaporation bath, bath temperature evaporation control box, vent flow rate and pressure of the air injection control points and vapor injection control of two.

Steam injection control for the user matching.

Features

1, the evaporation bath 3 hole bath.

2, automatic bath temperature control, automatic traffic detection.

3, replacing artificial flow regulation of trouble, easy to use.

4, evaporation time can be set to automatically alarm.

5 graphics LCD.

6, scalable data communication capabilities.

7, evaporation bath temperature, vent air velocity, pressure and sample evaporation time for all graphic LCD.

Technical Parameters

1, an air jet:

2, air pressure: ≯35Kpa

3, air flow rate: the flow rate of the exhaust port 1000 ± 100ml / s

4, evaporation bath: metal block baths, three test wells

5, evaporation bath temperature: 162.5 ± 1.5 ℃ (can be extended to 250 ℃)

6, the test hole temperature: 155 ± 5 ℃

7, heating power: 1800W

8, steam injection (optional):

9, the evaporation pressure: ≮35Kpa

10, steam flow: the flow rate of the exhaust port 1000 ± 100ml / s

11, evaporation bath temperature: 232-246 ℃ test hole temperature: 232 ± 5 ℃
