Iso 5660 Cone Calorimeter For Building Materials - China

ISO 5660 Cone Calorimeter for Building Materials is a modern device used to study the fire behavior of small samples of various materials in condensed phase.

Heat Release Rate, Mass loss rate, CO and CO2 generation, Oxygen consumption .

etc will be tested.

It is widely used in the field of Fire Safety Engineering.

Standard & Application:

• ISO 5660

Reaction to fire tests – Heat release, smoke production and mass loss rate • ASTM E 1354

Standard Test Method for Heat and Visible Smoke Release Rates for Materials and Products Using an Oxygen Consumption Calorimeter • BS 476 Pt.

15

Fire tests on building materials and structures – Method for measuring the rate of heat release of products

Application:

* Building Materials

* Rail

* IMO

* Wire & Cable

* Other Feature:

1 - Integrated body and 19' analysis rack.

2 - 17' touch screen panel type PC for the whole control and automatic testing .

3 - Automatic Spark Igniter to facilitate measurement of ignition time.

4 - Auto Split Shutter automatically opened to transmit radiation to the sample.

5 - Absorber-type glass protection door to facilitate sample observation during test and opening and closing.

6 - UK Servomex’s Gas Analyzer to exactly measure O2, CO, and CO2 concentrations up to 0.02%.

7 - Port, heated filter, and heated line to measure toxic gases.

8 - MFC(Mass Flow Controller) used for all gas flows, improving accuracy of and automatically controlling flux.

9 - Portable water cooling system without need for waterworks and plumbing when using the Heat Fluxmeter (for ISO 5660).

10 - UK RS' Load Cell with improved accuracy to measure mass loss rate.

11 - CC 2006 DAQ (Data Acquisition) Program controllable with the touch screen panel PC.

Test Result:

• Heat Flux, Unit: kW/m2 • Exhaust duct flow rate, Unit: l/s • C factor, Unit: 1/kg․m․K • Ignition time and Extinguisment time, Unit: s • Total oxygen consumption, Unit: g • Total Smoke Release, Unit: m/m2 • Mass loss and Mass loss rate, Unit: g, g/s

• Heat release rate, Unit: MJ/kg, kw/m2 • Effective heat of combustion, Unit: MJ/kg • Carbon monoxide yield, Unit: kg/kg • Carbon dioxide yield, Unit: kg/kg PS: (WLJCDM809)
