Martindale Rub Resistance Tester Machine - China

Mask textile fabric pilling tester Martindale rub resistance tester machine Garment fabric pilling tester for various woven fabrics and woven fabrics pilling performance test.

[Related standards]: GB/T4802.1-1997 DIN 53863.2 [Testing mode]: According to the specified method and experimental parameters, using nylon brush or single abrasive, the fabric is rubbed to pilling.

Then, under the specified lighting conditions, the pilling specimen will be compared with the sample photo to assess the pilling level.

Instrument characteristics: 1 - Adopt Japan THK imported slider, smooth running, silent effect is superb, suitable for long time continuous operation 2 - Adopt standard nylon brush, the rigidity of nylon wire must be uniform and consistent, so as to control the effect of nylon brush pilling.

3 - International popular streamline design, the surface is formed by a spraying, smooth and beautiful; 4 - Domestic Adopt double-station design, LCD display, digital setting.

Technical parameters.

1 - Furring and pilling movement track: 40mm diameter circular track movement.

2 - Adjustable brush: using effective height adjustable nylon brush.

3, specimen pressure: chemical fiber fabric pressure of 590cN.

4, specimen specifications: diameter 112.8mm round, area 100 square centimeters.

5, the number of times to choose: 1 ~ 9999 arbitrary preset.

6 - Specimen reciprocating speed: 60 times / min

7 - Power supply: Ac220V 50Hz

8, motor: power 60W speed 2800r / min

9 - Exterior dimensions: 540 (L) × 250 (W) × 345 (H) mm

10 - Weight: about 38Kg Relate:
