Materials And Composites Ignitability Test Apparatus - China

BS 476 Essentially Flat and Rigid Building Materials and Composites Ignitability Test Apparatus Application SJPM-F006 filter material performance tester is used to quickly and accurately detect the resistance and efficiency performance of various flat materials, such as glass fiber, PTFE, PET, PP melt-blown composite filter materials.

Product design conforms to many domestic and foreign industry standards such as EN1822-3: 2012, GB19083-2003, GB2626-2019 (KN95), IEST-RP-CC021.1 - Main Features The differential pressure measurement uses imported high-precision differential pressure transmitters, accurately measure the sample resistance The efficiency test uses Sujing high-precision photometer to detect the aerosol concentration in the upstream and downstream of the sample to ensure the authenticity and accuracy of the upstream and downstream samples.

The generator system uses special nozzles to meet the generating of oil and salt aerosols.

Polydisperse particle size distribution (optional monodisperse particle size) can occur, and the generating concentration can be adjusted quickly and stably Touch screen control, simple and intuitive operation, support for remote maintenance

Test result is automatically system calculated, displayed, and printed out Main technical parameters Test flow range is 15 ~ 100L / Min

Test sample specifications: 100 cm2 / 12cm2 (PTFE / glass fiber strip), equipped with multi-specification fixtures (flat masks, 3D masks) Resistance test: range 0 ~ 1000Pa, accuracy can reach 0.01Pa, automatically return to “0” function Efficiency test: efficiency range 80% -99.999%;

Dust sources: NaCl, PSL, DEHS, DOP Test time: resistance is tested separately for 10s, efficiency and resistance are tested simultaneously for 120s Power requirements: 220V, 50Hz, 1KW

Air source requirements: 0.5MPa, 120L / Min Dimensions: 800 * 800 * 1600mm (width * length * height)

Product weight: 100 Kg PS: (WLJCDM809)
