Raw Cotton Yg041 Analyzer Textile Testing Instrument - China

Raw cotton impurity analyzer YG041 raw cotton impurity analyzer textile testing instrument cotton testing instrument Changzhou China Fiber Factory Direct Sales tests various fabric resistance (anti) pilling performance.

A digital counter is used to control two sets of sine mechanisms, so that the sample and the grinding table form a compass trace to move relative to each other at a certain speed.

The nylon brush and abrasive or single-use abrasive are used to make chemical fiber knitted fabrics, chemical fiber woven fabrics, and combed blends.

Combed woolen fabrics, coarse woolen fabrics and other fabrics are rubbed and pilled, and graded against the fuzzing and pilling samples.

Preset times, automatic counting, Hall element acquisition times signal, LED display data.

This machine adopts linear guide rail as the sliding unit, which runs smoothly, with low noise and good consistency!

Motion track: φ 40mm ± 1mm ​​circular rail

Movement speed: 60r/min ± 1r/min

Brush height: 2mm ～ 10mm adjustable

Counting range: 1 time～999900 times Package Size:

650mm × 350mm × 440mm

Inner size of wooden box: 510*350*400mm

Applicable standards: GB/T4802.1-2008, DIN538863.2, JISL1076 Regarding the choice of weights: This machine has two weights with different weights, 100cN and 290cN respectively.

Users can choose different weights according to different experimental requirements.

When the weights need to be replaced, please hold the weights.

The weight can be removed by rotating the hour hand.

Three weights: 490cN do not put any weights;

590cN when putting 100cN weight;

780cN when putting 290cN weight.
