Rh Js06 Hydrostatic Head Tester Hot Sale Uk - China

Hydrostatic Head Tester Hydrostatic Pipe Static Pressure Tester hydrostatic pressure testing machine Product Introduction:

RH-JS06 Hydrostatic Head Tester is used test the resistance to water penetration for dense fabrics, e.g. medical protective clothing, umbrella, outdoor jacket, ducks, tarpaulins and tents.

Use dynamic test, static test and self defined program method to test the water repellency of textiles under certain pressure.

Standards:

BS EN 20811/3321/3424, ISO 811: Textiles - Determination of resistance to water penetration - Hydrostatic pressure test .

GB/T 4744: Textiles - Testing and evaluation for water resistance - Hydrostatic pressure method

AATCC 127: Test Method for Water Resistance: Hydrostatic Pressure

EN 1734: Rubber- or plastics coated fabrics - Determination of resistance to water penetration - Low pressure method

ISO 1420: Rubber- or plastics coated fabrics - Determination of resistance to penetration by water

FZ/T01004: Coated fabrics- Determination of resistance to penetration by water

ASTM F903C: Standard Test Method for Resistance of Materials Used in Protective Clothing to Penetration by Liquids

ASTM F1670: Standard Test Method for Resistance of Materials Used in Protective Clothing to Penetration by Synthetic Blood

ASTM F1671: Standard Test Method for Resistance of Materials Used in Protective Clothing to Penetration by Blood-Borne Pathogens Using Phi-X174 Bacteriophage Penetration as a Test System

ERT 120-1 160-0；AFNOR G07-057 Test Principle:

The hydrostatic head supported by a fabric is a measure of the opposition to the passage of water through the fabric.

A specimen is subjected to a steadily increasing pressure of water on one face, under standard conditions, until penetration occurs in three places.

The pressure at which the water penetrates the fabric at the third place is noted.

The water pressure may be applied from below or from above the test specimen.

Features:

1 - Operating terminal with touch screen or PC for test parameter settings.

2 - On less than 1m2 area, up to 50 different pressures including the pressure water supply.

3 - It is intelligent to distinguish the size and material of specimen, then provide optimized pressure rising solution and algorithm.

4 - High accuracy pressure control.

Selectively adjustable input pressure in each individual module reduces the wearing of solenoid valves, endures a long service life.

5 - All metal components that come into contact with the medium are made of high-quality stainless steel.

6 - Operator-friendly display interface provides multi languages to suit the most varied customer requirements.

7 - It is convenient to calibrate pressure during testing, meaning that the system may continue running during calibration(optional).




8 - Multistage protections are from electric partt, mechanical part as well as software.

9 - Reliable data exchange via TCP/IP protocol.
