Textile Fabric Martindale Abrasion Resistance Test Equipment Instrument Tester Testing Machine - China

textile fabric martindale abrasion Resistance test equipment Instrument Tester Testing Machine

textile fabric martindale abrasion Resistance test equipment Instrument Tester Testing Machine Used for testing the performance of the wearing resistance, abrasion, appearance change (pilling degree/class) of the textiles and membrane materials.

Standard

GB/T 21196, GB/T 4802.2, GB/T 13775, FZ/T 20020, ISO 12945-2, ISO 12947

ASTM D4966, ASTM D4970, ASTM D3886, JIS L1096, IWS Tm196/ TM112 Feature

1, lissajous curve

2, hammer adopt 304stainless steel

3, Platen adopts special aluminum alloy production, Guarantee the long time use without deformation

4, Needle roller bearing type connection transmission, ensure each bench tests without error

5, Can be preset set to run the program, a variety of counting method(Add count and subtract counter)

6, Four location independent cumulative counts, may at any time simplex lock, convenient test management Parameter

1 - Number of working position: 4digital 2 - Counting range: 0~999999 times

3 - The Max.

travel: Horizontal orientation 60.5±0.5mm Longitudinal orientation 24±0.5mm

4 - Pressurized material mass:

a, holder: 198±2g

b, Fabric sample weight: 395±2g

c, Furniture decoration sample weight: 594±2g

d, Btype holder: 155±1 g

e, Stainless steel butterfly pieces: 260±1g

5, diameter of friction:

Atype 198g(1.96N)friction head Φ28.65 ±0.05mm

Btype 155g(1.52N)friction head Φ90 ±0.10mm

6, Relative moving speed of clamp and grinding table: 50±2r/min(20-70r/m in adjustable)

7, Pressing hammer of sample loading weight: 2385±10g

8, dimension: 600×550×410mm

9, power: Ac220V 50Hz 500W

10, weight: 75kg
