Textile Fabric Tensile Testing Machine Ht 101pt Material Tester - China

Textile fabric tensile testing machine HT-101PT material tester Textile fabric tensile testing machine HT-101PT material tester

Knitted fabrics are divided into two types according to the weaving method, weft knitted fabrics and warp knitted fabrics.

Weft knitted fabrics often use low-elastic polyester yarns or special-shaped polyester yarns, nylon yarns, cotton yarns, wool yarns, etc.

as raw materials, using plain weave, variable plain weave, rib plain weave, double rib plain weave, jacquard weave, wool Loops, etc., are woven on various weft knitting machines.

The tensile testing machine is a new type of material testing machine that combines electronic technology with software technology and mechanical transmission.

It uses a stepping motor system as a power source; it uses precision ball screws and guide rods, uses a 0.5-level precision force sensor, and passes high precision Force measurement system to achieve measurement.

Product performance introduction

High measurement accuracy, certified by a third-party testing agency

High speed, low vibration, low noise motor drive device

Multilingual application function, adapt to different countries

With flexible, graph, data sheet, report viewing and printing functions

With automatic homing function that automatically returns to the start of the test after the test is completed Product specification

Model: HT-101PT

Subdivision model: -005, -01, -02, -05, -1, -2, -5, -10

Capacity: KN, 0.05kN, 0.1 kN, 0.2 kN, 0.5kN, 1 kN, 2kN, 5kN, 10KN

KG: 5kg, 10kg, 20kg, 50kg, 100kg, 200kg, 500kg, 1000kg

lb: 11, 22, 44, 110, 220, 440, 1102, 2204 Basic parameters

Effective measuring force range: 0.4%～100%FS

Force value accuracy: within ±1% of the indicated value

Force resolution: 1/200 000

Power magnification: X1, X2, X5, X10, X20, X50, X100 and other seven gears, full automatic shift switching

Deformation measurement range: 2%～FS

Deformation indication accuracy: within ±1% of indication More parameters

Safety device: 1 - Mechanical travel switch protection 2 - Emergency stop switch for emergency braking

Overload protection: up to 100% of the maximum load, the machine will automatically shut down for protection

Accessories: 1 power cord; 1 manual; 1 certificate To learn more about textile testing instruments, please pay attention to QINSUN INSTRUMENTS!
